Mean Well RPD-65C Power Supply 65W 5V 12V
$28.45 USD
Unit price /
Unavailable
Description
Description
Features
| Universal AC input/Full range |
| 12V or 24V high peak output current capability |
| Low leakage current<1mA |
| Protections: Short circuit/ Overload/ Over voltage |
| 60W free air convection, 77.1W with 18CFM forced air |
| 100% full load burn-in test |
| Fixed switching frequency at 65KHz |
| 2 years warranty |
General Specification
| AC input voltage range | 90~264VAC; 127~370VDC |
| AC inrush current | Cold start 25A/115VAC |
| Leakage current | <1mA |
| Overload protection | 150 ~ 208% rated output power |
| Over-voltage protection | 115%~135% rated output voltage |
| Setup, rise, hold up time | 800ms, 20ms, 20ms |
| Withstand voltage | I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:1.5KVAC |
| Working temperature | -20~+65°C |
| Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60min. Each along X, Y, Z axes |
| Safety standards | UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved |
| EMC standards | EN55011 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 |
| Connection | I/P: 3 Pin JST VHR, O/P: 6 Pin JST SVH-21T-P1.1 |
| Dimension (LxWxH) | 127x76x29 |
| Packing | 63pcs / 16kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesRPD Series
-
Power Rating60 Watt
-
Output Voltage12 Volt
-
Rated Current4.5 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~60°C
-
Warranty2 Year
-
Length5 in
-
Width2.99 in
-
Height1.14 in
-
Weight0.53 lb
