Mean Well MPQ-200C Power Supply 200W 5V 15V -5V -15V
$102.27 USD
Unit price /
Unavailable
Description
Description
Features
| Universal AC input/Full range |
| Low leakage current < 150μA |
| Protections: Short circuit/Overload/Over voltage/Over temperature |
| Free air convection for 140W and forced air convection for 200W |
| Medical safety approved(2 x MOPP between primary to secondary) |
| With power good and fail signal output |
| Built-in remote ON-OFF control |
| Built-in remote sense function |
| Fixed switching frequency at 100KHz |
| 3 years warranty |
General Specification
| AC input voltage range | 90~264VAC; 127~370VDC |
| AC inrush current | Cold start 40A |
| Leakage current | <150 μA/264VAC |
| Overload protection | 120 ~ 160% rated output power |
| Over voltage protection | 115%~135% rated output voltage |
| Setup, rise, hold up time | 1000ms, 20ms, 16ms |
| Withstand voltage | I/P-O/P:4KVAC, I/P-FG:2KVAC, O/P-FG:1.5KVAC |
| Working temperature | -20~+70°C |
| Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min. Each along X, Y, Z axes |
| Safety standards | IEC60601-1, BS EN/EN60601-1 |
| EMC standards | EN55011 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 |
| Connection | Input: JST B3P-VH, Output: JST B8P-VH |
| Dimension (LxWxH) | 177.8x107.2x35.5 |
| Packing | 24pcs / 16.8kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesMPQ Series
-
Power Rating200 Watt
-
Output Voltage5 Volt
-
Rated Current12 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length7 in
-
Width4.22 in
-
Height1.4 in
-
Weight1.46 lb
