Mean Well ADS-15524 Power Supply 154.2W 48V 2.9A - 5V Output
$74.65 USD
Unit price /
Unavailable
Description
Description
Features
| Universal AC input / Full range |
| Built-in active PFC function |
| Protections: Short circuit / Overload / Over voltage |
| Cooling by free air convection |
| 100% full load burn-in test |
| Fixed switching frequency at PFC 67KHz, PWM 134KHz |
| 2 years warranty |
General Specification
I/P-O/P:3KVAC; I/P-FG:2.0KVAC; O/P-FG:0.5KVAC| AC input voltage range | 88~264VAC; 124~370VDC |
| AC inrush current | COLD START 23A/115VAC; 45A/230VAC |
| Leakage current | <1mA / 240VAC |
| Overload protection | 105%~135% rated output power |
| Over-voltage protection | 115%~135% rated output voltage |
| Setup, rise, hold up time | 1000ms, 2000ms, 24ms |
| Withstand voltage | |
| Working temperature | -10~+60°C |
| Vibration | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes |
| Safety standards | UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved |
| Case No. | 906 |
| Dimension (LxWxH) | 199x110x50 mm |
| Packing | 16pcs / 16kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesADS Series
-
Power Rating154.2 Watt
-
Output Voltage48 Volt
-
Rated Current2.9 Ampere
-
Input Voltage88V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty2 Year
-
Length7.83 in
-
Width4.33 in
-
Height1.97 in
-
Weight2.2 lb
