Mean Well NKN-5K-148 5KW True Sine Wave Inverter with AC Charger/UPS, 48V In 110V Out

$3,703.12 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

Features:

  • Multi-functional All-in-One device (AC-DC Charger + DC-AC Inverter for Load + AC Bypass for Load)
  • Built-in AC-DC high power charger up to 4520W
  • DC-AC pure sine wave output (THD<3%)
  • Instantaneous peak power of up to 10KW for AC output
  • Up to 6 units of AC output can be paralleled, expanding wattage up to 30KW (5+1 units)
  • Utilizes 3 NTN-5K unidirectional AC outputs, configurable for 3Ø4W usage
  • -30~+70℃ ultra-wide temperature range, suitable for global deployment or installation in enclosed environments
  • Built-in remote ON/OFF control
  • Protections:
    • DC input: Reverse Polarity, Low Voltage Warning and Shutdown, Over Voltage, Battery Over Discharge
    • AC output: Short Circuit, Overload, Over Temperature
  • Built-in Modbus or CAN bus communication monitoring
  • Optional intelligent controllers available for purchase:
    • CMU2E (Stand-Alone Vertical Mounting / Rail Mounting) or CMU2E-R (Rack System Installation)
  • Dimensions (length x width x height): 460 x 211 x 83.5mm
  • PCB coating for basic moisture/dust / dirt protection
  • Certifications: CB / TUV / RCM / EAC / CE / UKCA / FCC
  • Compatible with lead acid or lithium batteries
  • 5 years warranty

General Specification

DC input voltage range

(19 ~ 33Vdc) (38 ~ 66Vdc)

AC output frequency

The default setting set at 50±0.1Hz

50/60Hz selectable by DIP S.W

LOW & HIGH

ALARM, SHUTDOWN, RESTART

Reverse Polarity

No damage, re-power on to recover after fault condition is removed

Over Temperature

Shut down o/p voltage, recovers automatically after temperature goes down

Output Short

Shut down the o/p voltage, and re-power it to recover

OVERLOAD (Typ.)

105 - 115% load for 180 sec., 115% - 150% load for 10 sec.

Protection type: Shut down o/p voltage, re-power on to recover

Remote Control

Power ON-OFF remote control by front panel dry contact connector(by RELAY), Open : Remote off ; Short: Normal work

Communication

MODBus-RTU (RS-485) / CANBus

Withstand voltage

(DC I/P - AC:3.0KVAC) (AC - FG:1.5KVAC)

Working temperature

-30 ~ +70℃(Refer to “Derating curve”)

Safety standards

CB IEC62368-1, CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, AS/NZS 62368.1, EAC TP TC 004 approved

Dimension (LxWxH)

460x211x83.5mm

Specifications

  • Brand
    Mean Well
  • Series
    Mean Well NTN-5K Series
  • Power Rating
    4000 Watt
  • Output Voltage
    100 Volt
  • Rated Current
    100 Ampere
  • Input Voltage
    38V~66V
  • Standards Met
    CB,CE,EAC,EN,FC
  • Operation Mode
    Constant Current,Constant Voltage
  • Operating Temperature
    -30°C~70°C
  • Warranty
    5 Year
  • Length
    18.11 in
  • Width
    8.31 in
  • Height
    3.29 in
  • Weight
    23.15 lb
