Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well RSDW20UW-05 Ultra-wide input DC/DC LED Driver 20W 5V - Heavy Duty 4A
Mean Well RSDW20UW-05 Ultra-wide input DC/DC LED Driver 20W 5V - He...
Overview
RSDW20UW-05 is the 5V output model of this series: rated power 20W, typical efficiency 85.5%.
RSDW20UW and RDDW20UW series are 20W module type DC-DC reliable railway converter with 2"x1" package. It features international standard pins, a high efficiency up to 89%, wide working temperature range -40~+95℃, 3KVAC I/P-O/P isolation voltage, meet EN50155 with external circuits, continuous-mode short circuit protection, etc. The models account for 8.5~160VDC 18:1 ultra-wide input range, and various output voltage, 5V/12V/15V for single output and ±12V/±15V/±24V for dual outputs, which are suitable for railway, trams, buses and also can be used in the harsh environment with high vibration, high dust, extremely low or high temperature, etc.
Features
- Compliance with railway standard EN50155
- DIP 2"x1" package with standard pinout
- 18:1(8.5~160Vdc) ultra-wide input range
- Wide operating temperature range -40 ~ +95℃
- No minimum load required
- Full encapsulated
- Protections: Short circuit (Continuous) / Overload / Over Voltage / Input under voltage
- 3KVAC I/O isolation
- Operating altitude up to 5000 meters (Note.5)
- Remote ON/OFF control
- 3 years warranty
Specifications
MODEL SELECTION TABLE
- INPUT VOLTAGE (RANGE)
- Normal 12V,24V,48V,72V,96V,110V (8.5 ~ 160V)
- INPUT CURRENT NO LOAD
- 5mA
- INPUT CURRENT FULL LOAD
- 323mA
- OUTPUT VOLTAGE
- 5V
- OUTPUT CURRENT
- 4000mA
- EFFICIENCY (Typ.)
- 85.5%
- CAPACITOR LOAD (MAX.)* For each output
- 6800μF
INPUT
- VOLTAGE RANGE
- 8.5 ~ 160Vdc
- SURGE VOLTAGE (100ms max.)
- 200Vdc
- FILTER
- Pi type
- PROTECTION
- 4A fast acting fuse
OUTPUT
- VOLTAGE ACCURACY
- ±1.0%
- RATED POWER
- 20W
- RIPPLE & NOISENote.2
- 100mVp-p
- LINE REGULATIONNote.3
- ±0.2%
- LOAD REGULATIONNote.4
- Single output models: ±0.3%, Dual output models:±1%
- CROSS REGULATION
- ±5% @ 25%~100% load
- SWITCHING FREQUENCY (Typ.)
- 200KHz
- EXTERNAL TRIM ADJ. RANGE (Typ.)
- -20% ~ +15% (Single output model only)
PROTECTION
- SHORT CIRCUIT
- Protection type : Continuous, automatic recovery
- OVERLOAD
- 110 ~ 180% rated output power Protection type : Recovers automatically after fault condition is removed
- OVER VOLTAGE
- Protection type : Clamp by diode
- UNDER VOLTAGE LOCKOUT Start-up voltage
- 9Vdc
- UNDER VOLTAGE LOCKOUT Shutdown voltage
- 8Vdc
FUNCTION
- REMOTE CONTROL
- Power ON: >4.0~160Vdc or open circuit Power OFF: <1.2Vdc or short
ENVIRONMENT
- COOLING
- Free-air convection
- WORKING TEMP.
- -40 ~ +95℃ (Refer to "Derating Curve")
- CASE TEMPERATURE
- +105℃ max. (+110℃ thermal shutdown)
- WORKING HUMIDITY
- 20% ~ 90% RH non-condensing
- STORAGE TEMP., HUMIDITY
- -55 ~ +125℃, 10 ~ 95% RH non-condensing
- TEMP. COEFFICIENT
- 0.03% / ℃ (0 ~ 95℃)
- SOLDERING TEMPERATURE
- 1.5mm from case of 1 ~ 3sec./260℃ max.
- VIBRATION
- 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
- OPERATING ALTITUDENote.5
- 5000 meters
SAFETY & EMC ( Note.6)
- SAFETY STANDARDS
- UL62368-1, EAC TP TC 004 approved
- WITHSTAND VOLTAGE
- I/P-O/P:3KVAC
- ISOLATION RESISTANCE
- I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
- ISOLATION CAPACITANCE (Typ.)
- 20pF
- EMC EMISSION
-
Parameter Standard Test Level Conducted BS EN/EN50121-3-2 Class A/B with external components Radiated BS EN/EN50121-3-2 N/A - EMC IMMUNITY
-
Parameter Standard Test Level ESD BS EN/EN61000-4-2 Level 3, ±8KV air, ±6KV contact Radiated Susceptibility BS EN/EN61000-4-3 Level 3, 80~1000MHz, 20V/m EFT/Bursts BS EN/EN61000-4-4 Level 3, On power input port,±2KV external input capacitor required Surge BS EN/EN61000-4-5 Level 4, Line to earth, ±4KV Line to Line, ±2KV Conducted BS EN/EN61000-4-6 Level 3, 0.15~80MHz, 10V - RAILWAY STANDARD
- EN50155 including EN61373 for shock & vibration, EN50121-3-2 for EMC
OTHERS
- MTBF
- 1570Khrs MIL-HDBK-217F(25℃)
- DIMENSION (L*W*H)
- 50.8*25.4*10.2mm (2*1*0.4 inch)
- CASE MATERIAL
- Black coated copper with Non-Conductive Base
- PACKING
- 35g ; 12pcs/per tube, 300pcs/25 tube/per carton
Test conditions and notes6
- 1.All parameters are specified at normal input(72Vdc), rated load, 25℃ 70% RH ambient.
- 2.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1μf & 47μf capacitor.
- 3.Line regulation is measured from low line to high line at rated load.
- 4.Load regulation is measured from 0% to 100% rated load.
- 5.The ambient temperature derating of 3.5℃/1000m for operating altitude higher than 2000m(6500ft).
- 6.The final equipment must be re-confirm that it still meet EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.”(as available on http://www.meanwell.com)
Technical drawings
Typical applications
- Bus, tram, metro or railway system
- Telecom/datacom system
- Wireless network
- Industrial control facility
- Instrument
- Analyzer
- Highly vibrating, heavily dusty, extremely low or high temperature harsh environment
Downloads
Certificates5
FAQ
Can I use the RSDW20UW-05 for 5V industrial electronics where the input source varies widely?
Yes. This model provides a constant 5V output up to 4A and 20W, and its specified input range is 8.5~160Vdc, which is wider than the standard RSDW20H models. That makes it suitable for 5V electronics operating from sources that fall anywhere within that stated range.
Is the RSDW20UW-05 appropriate for 5V embedded systems in heavy-duty or railway-related equipment?
It can be used for 5V embedded loads that require up to 4A and 20W. The provided features include EN50155 railway compliance, 3KVAC isolation, and an operating temperature range of -40°C to +95°C.
Can this converter support 5V display, logging, or communication modules in mobile equipment?
It is a fit for 5V display, logging, or communication modules if the total load remains at or below 4A and 20W. The 8.5~160Vdc input range can be useful in equipment where the available input varies across a broad specified range.
Is the RSDW20UW-05 suitable for outdoor or high-temperature environments?
The operating temperature range is -40°C to +95°C, so it supports a wider temperature span than the RSDW20H series. No IP rating is listed in the specs, so outdoor exposure still requires a protective enclosure.
How does the RSDW20UW-05 compare with the other ultra-wide input versions?
The RSDW20UW-05, -12, and -15 all share 20W power, 8.5~160Vdc input, 50.8 × 25.4 × 10.2 mm dimensions, 35g weight, and -40°C to +95°C operation. Their output ratings differ: the -05 is 5V at 4A, the -12 is 12V at 1.67A, and the -15 is 15V at 1.33A.
