Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well IQB150W8-48 DC-DC Converter - 150W - 9~75V in 48V out 3.125A

Name: Mean Well IQB150W8-48 DC-DC Converter - 150W - 9~75V in 48V out 3.125A
Brand: Mean Well
SKU: IQB150W8-48
Price: 128.93 USD
Availability: InStock

$128.93 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

The Mean Well IQB150W8-48 is a 150W isolated DC-DC converter in an industry-standard quarter-brick package (2.28 × 1.45 × 0.5 inch), delivering a regulated 48V DC output at up to 3.125A. Its 8:1 ultra-wide 9~75Vdc input covers nominal 12V, 24V, 36V, 48V and 72V systems from a single part number.

Fully encapsulated on an aluminium base plate, the IQB150W8-48 runs from -40°C to +90°C on natural convection with no minimum load, and offers 1.6kVac (2.2kVdc) I/O isolation, remote ON/OFF control, remote sense and ±10% output trim. Short circuit, overload, over voltage, over temperature and input under-voltage protection are all built in — suited to telecom and datacom systems, wireless networks, industrial control, instruments and analysers, including high-vibration and dusty environments.

Key Features

✓Regulated output: 48V DC at up to 3.125A (150W max)
✓8:1 ultra-wide input range: 9~75Vdc (nominal 12/24/36/48/72V)
✓Quarter-brick package with industry-standard pin-out: 57.9 × 36.8 × 12.7 mm
✓High efficiency up to 87%
✓No minimum load required; natural convection cooling
✓1.6kVac (2.2kVdc) I/O isolation, fully encapsulated
✓Remote ON/OFF control, remote sense and ±10% output trim
✓Protections: short circuit (continuous), overload, over voltage, over temperature, input under-voltage lockout
✓Certifications: CE, EAC (IEC 62368-1, EAC TP TC 020)
✓Wide operating temperature: -40°C to +90°C
✓3-year Mean Well warranty

Specifications

Brand

Mean Well
Standards Met

CE,EAC
Operation Mode

Constant Voltage
Length

2.28 in
Width

1.45 in
Height

0.5 in
Weight

0.17 lb

File Downloads

::specification::
