Test Product With Variants

$200.00 USD
Shipping calculated at checkout.
Size

|

Your order will be processed within 24 hours

Description

Features

150~1500Vdc 10:1 ultra-wide input range
57mm slim width
4KVac I/O high isolation(Reinforced isolation)
Protections: Short circuit / Overload / Over voltage /Input reverse polarity / Input under voltage protection
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
-30~+80°C wide working temperature
Overvoltage category II
Operating altitude up to 5000 meters
DC OK relay contact
DC output voltage adjustable(+20%)
3 years warranty

General Specification

Overload protection 105%~135% rated output power; Protection type: Hiccup mode, recovers automatically after fault condition is removed
Over-voltage protection

5V:6.6~8.4V; 12V:16.5~21V; 24V:30~38V;

48V:55~60V; Protection mode: Hiccup mode, recovers automatically after the fault condition is removed

REVERSE POLARITY By internal Bridge Diode, no damage recovers automatically after the fault condition removed
Withstand voltage I/P-O/P:4KVDC O/P-DC OK:0.5KVAC
Working temperature -30~+80°C
Safety standards IEC62109-1(LVD), EAC TP TC 004 approved; Design refers to UL1741(By request)
EMC standards With external components Compliance to EN55032 Class A;EN61000-3-,3,EN61000-4-2,3,4,5,6,8,11
Dimension (LxWxH)(mm) 57*93.5*105mm
Packing 16pcs/12.8Kg
