Over 15 years experience of providing support of MEAN WELL Power Supplies
Description
Description
Features:
- Constant power mode output with multiple stages selectable by NFC setting(H-type)
- Constant voltage mode output (12V/24V/48V)
- Plastic housing with class II/2 and PFC design
- Flicker-free, complying with IEEE1789/ErP
- Standby power consumption <0.5W
- Meet emergency lighting (EL) application
- Fully encapsulated with IP67
- Minimum dimming level <1% (DALI-2 DT6)
- Dimming functions: 3 in 1 dimming (Dim-to-off) DALI-1 + Push dimming
- 5 years warranty
General Specification
AC input voltage range
110305VAC 155431VDC
AC inrush current (max.)
COLD START 15A(twidth=310μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
Overload protection
105 ~ 150% rated output power
Protection type: Hiccup mode, recovers automatically after fault condition is removed
Over-voltage protection
| 1417V | 2735V | 56~63V |
Shut down output voltage, and re-power it to recover
Over temperature protection
Shut down output voltage, recovers automatically after fault condition is removed
Withstand voltage
I/P-O/P:3.75KVAC
Working temperature
Tcase=-25~90℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
Safety standards
ENEC BS EN/EN61347-1, BS EN/EN61347-2-13(EL) appendix J suitable for emergency installations; BS EN/EN62384 independent, GB19510.14, GB19510.1, EAC TP TC 004 approved;
Dimension (LxWxH)
141.5x49x32mm
Specifications
Specifications
-
BrandMean Well
-
SeriesMean Well XLN Series
-
Power Rating60 Watt
-
Output Voltage24 Volt
-
Rated Current2.5 Ampere
-
Input Voltage110V~305V
-
Standards MetCB,CCC,CE,EAC,ENEC,SELV
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~90°C
-
Warranty5 Year
-
Length5.57 in
-
Width1.26 in
-
Height1.93 in
