Description
Description
Features:
- Constant power mode output with multiple stages selectable by dip switch or NFC setting(H-type)
- Constant voltage mode output (12V/24V/48V)
- Plastic housing with class II/2 and PFC design
- Flicker-free, complying with IEEE1789/ErP
- Standby power consumption <0.5W
- Meet emergency lighting (EL) function application
- Minimum dimming level 0.1% (DALI-2 DT6)
- Dimming functions: 3 in 1 dimming (Dim-to-off) DALI-1 + Push dimming
- 5 years warranty
General Specification
AC input voltage range
110-305VAC 155-431VDC
AC inrush current (max.)
COLD START 15A(twidth=310μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
Overload protection
105 - 150% rated output power
Protection type: Hiccup mode, which recovers automatically after the fault condition is removed.
Over-voltage protection
(14-17V) (27-35V) (56-63V)
Shut down output voltage, and re-power it to recover
Over temperature protection
Shut down output voltage, recovers automatically after fault condition is removed
Withstand voltage
I/P-O/P:3.75KVAC
Working temperature
Tcase=-25~90℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
Safety standards
ENEC BS EN/EN61347-1, BS EN/EN61347-2-13(EL) appendix J suitable for emergency installations; BS EN/EN62384 independent, GB19510.14, GB19510.1, EAC TP TC 004 approved;
Dimension (LxWxH)
176x45x32mm , 136x45x32mm
Specifications
Specifications
-
BrandMean Well
-
SeriesMean Well XLC Series
-
Power Rating60 Watt
-
Output Voltage48 Volt
-
Rated Current1.25 Ampere
-
Input Voltage110V~305V
-
Standards MetCB,CCC,CE,EAC,ENEC,SELV
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~90°C
-
Warranty5 Year
-
Length6.93 in
-
Width1.26 in
-
Height1.77 in
