Mean Well TDR-480-48 Single Output Industrial Power Supply 480W 48V...
$131.97 USD
$138.77
Unit price /
Unavailable
Description
Description
The TDR-480 is a 480W Mean Well power converter (input range: 340~550VAC, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 340~550VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ DC OK relay contact output
- ✓ Safety approvals: -40 ~ +85 ± 0.03%/ ℃ ℃ , 10 ~ 95% RH (0 ~ 50 ) ℃ Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6 UL508, IEC60950-1 CB
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesTDR Series
-
Power Rating480 Watt
-
Output Voltage48 Volt
-
Rated Current10 Ampere
-
Input Voltage340V~550V
-
Standards MetCE,cUL,EAC,TUV
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length5.06 in
-
Width4.93 in
-
Height3.37 in
-
Weight3.33 lb
