Mean Well SPB09C-12 DC-DC Converter - 9W - 36~75V in 12V out

$17.22 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

Features

SIP8 package with industry-standard pinout
2:1 wide input range
Wide operating temperature range -40~+90°C
No minimum load required
High efficiency up to 89%
Protection: Short circuit(continuous)/Overload/Input under voltage
1.5KVDC I/O isolation

Remote ON/OFF control

9V model available(optional)

3 years warranty


General Specification

Voltage accuracy ±1.5%
Vibration 10 ~ 500Hz, 2G 10min./1 cycle, the period for 60min. each along X, Y, and Z axes
Cooling Free-air convection
Short circuit protection Continuous, auto-recovery
Working temperature -40°C to +90°C
EMC Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient 0.03% / ℃ (0 ~ 70℃)
Dimension (LxWxH) (mm) 24*9.6*11.2mm
Potting material UL 94V-0 rated

Specifications

  • Brand
    Mean Well
  • Series
    SPB Series
  • Power Rating
    9 Watt
  • Output Voltage
    12 Volt
  • Rated Current
    0.75 Ampere
  • Input Voltage
    36V~75V
  • Standards Met
    CE,EAC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~90°C
  • Warranty
    3 Year
  • Length
    0.98 in
  • Width
    0.44 in
  • Height
    0.38 in
  • Weight
    0.01 lb

File Downloads
