Mean Well SPA01C-05 DC-DC Converter - 1W - 36~75V in 5V out
$9.09 USD
Unit price /
Unavailable
Description
Description
"
Features
- Wide 2:1 DC input range
- In/out capacitance 1000pF
- Protections: Short circuit / Overload
- 1500 VDC I/O isolation
- Built-in EMI filter without external components
- Cooling by free air convection
- 100% full load burn-in test
- Low cost
- High relibility
- 2 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSPA Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage36V~75V
-
Standards MetCE,EAC,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty2 Year
-
Length0.69 in
-
Width0.44 in
-
Height0.31 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
