Mean Well SP-320-48 Power Supply 320W 48V 6.7A

Name: Mean Well SP-320-48 Power Supply 320W 48V 6.7A
Brand: Mean Well
SKU: SP-320-48
Price: 58.97 USD
Availability: InStock

320W Single Output with PFC Function

SKU SP-320-48

$58.97 USD

Shipping calculated at checkout.

Select model — 3 in this family

SP-320-48

SP-75-48 75W 48V In stock$31.87 USD

SP-320-48 320W 48V Backorder$58.97 USD

SP-480-48 480W 48V Backorder$127.53 USD

Product variants

End of Life, Succeeded by RSP-320-48

Available to order

Overview

SP-320-48 is the 48V output model of this series: rated current 6.7A, rated power 321.6W, typical efficiency 89%.

Features

Universal AC input / Full range
Built-in active PFC function, PF>0.95
Protections: Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC Fan
Built-in fan speed control
Fixed switching frequency at 100KHz
3 years warranty

Specifications

SP-320-48Specifications from the official datasheet (2021-09-15 edition)Download datasheet PDF

OUTPUT

DC VOLTAGE: 48V
RATED CURRENT: 6.7A
CURRENT RANGE: 0 ~ 6.7A
RATED POWER: 321.6W
RIPPLE & NOISE (max.)^Note.2: 240mVp-p
VOLTAGE ADJ. RANGE: 41 ~ 56V
VOLTAGE TOLERANCE^Note.3: ±1.0%
LINE REGULATION: ±0.2%
LOAD REGULATION: ±0.5%
SETUP, RISE TIME: 800ms, 50ms/230VAC 2500ms, 50ms/115VAC at full load
HOLD UP TIME (Typ.): 16ms/230VAC 16ms/115VAC at full load

INPUT

VOLTAGE RANGE^Note.5: 88 ~ 264VAC 124 ~ 370VDC
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF>0.95/230VAC PF>0.98/115VAC at full load
EFFICIENCY (Typ.): 89%
AC CURRENT (Typ.) 115VAC: 2.5A 5A
AC CURRENT (Typ.) 230VAC: 1.5A 2.5A
INRUSH CURRENT (Typ.): 20A/115VAC 40A/230VAC
LEAKAGE CURRENT: <1mA / 240VAC

PROTECTION

OVERLOAD: 105 ~ 135% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE: 57.6 ~ 67.2V Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.: -20 ~ +65℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

SAFETY & EMC (Note 4)

SAFETY STANDARDS: UL60950-1 approved
WITHSTAND VOLTAGE: I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3
EMC IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A

OTHERS

MTBF: 207K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 215*115*50mm (L*W*H)
PACKING: 1.1Kg; 12pcs/14Kg/0.9CUFT

Test conditions and notes5

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com)
5. Derating may be needed under low input voltages. Please check the derating curve for more details.

Technical drawings

SP-320-48 Mechanical Specification — Mechanical Specification

SP-320-48 Derating Curve — Derating Curve

Downloads

Datasheet1

SP-320-48 datasheetSP_320_spec.pdf · 2021-09-15 edition PDF Download

FAQ

Can I use the SP-320-48 for 48V telecom or networking equipment?

Yes, if the equipment is designed for 48V DC input and the total load stays within 320W and 6.7A. That makes it relevant for 48V communications, networking, and industrial electronics that need a regulated DC source.

Is the SP-320-48 suitable for a 48V industrial control system?

It can be used for 48V control hardware where the full connected demand does not exceed 320W or 6.7A. Its constant voltage output is intended for equipment that requires a fixed 48V DC supply.

Would this model work for 48V automation or embedded devices with moderate current demand?

Yes, provided the devices require 48V DC and the combined load remains at or below 320W and 6.7A. It fits applications where voltage is higher but current demand is lower than comparable 12V or 24V systems.

Can the SP-320-48 power several 48V loads from one supply?

It can, as long as the total output requirement across all connected 48V devices stays within 320W and 6.7A. That makes it practical for shared 48V DC distribution in control or communications environments.

Is the SP-320-48 intended for outdoor use?

The operating temperature range is specified as -20°C to +65°C, but no IP rating is provided in the available specs. Based on that information, temperature capability is known, while direct outdoor exposure suitability is not confirmed.

How does the SP-320-48 compare with the other SP-320 variants?

The listed SP-320 models include SP-320-12 at 300W, 12V, 25A; SP-320-27 at 315.9W, 27V, 11.7A; SP-320-36 at 316.8W, 36V, 8.8A; and SP-320-48 at 321.6W, 48V, 6.7A. They are in the same power class, with the differences centered on output voltage and resulting current capacity.
