Mean Well SMT01A-15 DC-DC Converter - 1W - 9~18V in 15V out
$10.14 USD
Unit price /
Unavailable
Description
Description
Features
| SMD package with industry-standard pinout |
| 2:1 wide input range |
| Operating temperature range -40~+90℃ |
| Comply to BS EN/EN55032 radiated Class A without additional components |
| Optional reel packing |
| Protections: Short circuit(Continuous)/Overload |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±2.0% |
| Overload Protection | 130~200% rated output power |
| Cooling | Free-air convection |
| Short circuit protection | Continuous, automatic recovery |
| Working temperature | -40 ~ +90℃ (Refer to "Derating Curve") |
| EMC | Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.03% / ℃ (0 ~ 85℃) |
| Dimension (LxWxH) (mm) | 15.24*10.9*7.1mm (0.6*0.43*0.28 inch) |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSMT Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage9V~18V
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
