Mean Well SKA40A-12 DC-DC Converter - 35W - 9~18V in 12V out

$47.46 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

Features

2" x 1" compact size
2:1 wide input range
1500VDC I/O isolation
Built-in remote ON/OFF control
Built-in EMI filter
Protection: Short circuit / Overload / Input and output over voltage
Cooling by free air convection
Built-in remote sense
100% full load burn-in test
Low cost, high reliability
Trimming output (±10%)
High efficiency up to 93%
Output 3.3V/9V models available
2 years warranty

General Specification

Voltage set point accuracy ±2% (max.)
Line regulation ±0.5% (max.)
Load regulation ±0.5% (max.)@10~100% load
Overload protection 110%~180%, auto-recovery
Efficiency 92%
Over voltage protection Clamp by TVS diode
I/O isolation voltage 1500VDC (min.)
I/O isolation resistance 100MQ(min.) @500VDC
Working temperature -40~+80°C (refer to output derating curve)
Storage temperature -55°C to +105°C
Case material Six-sided shield metal case
EMC Compliance to EN55022 class A, EN61000-4-2,3,4,5,6,8, FCC part15 class A
Dimension (LxWxH) (mm) 2" x 2" x 0.43"

Specifications

  • Brand
    Mean Well
  • Series
    SKA Series
  • Power Rating
    35 Watt
  • Output Voltage
    12 Volt
  • Rated Current
    3.33 Ampere
  • Input Voltage
    9V~18V
  • Standards Met
    CE,EMC,FCC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~80°C
  • Warranty
    2 Year
  • Length
    2 in
  • Width
    2 in
  • Height
    0.43 in
  • Weight
    0.13 lb
