Mean Well RSDW20UW-12 Ultra-wide input DC/DC LED Driver 20W 12V - H...
$64.08 USD
Unit price /
Unavailable
Description
Description
The RSDW20UW is a 20W Mean Well power converter (input range: 8.5~160Vdc).
Key Features
- ✓ Input voltage range: 8.5~160Vdc
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Railway standards: EN45545-2 (fire), EN50155 / IEC60571, IEC61373 (shock & vibration)
- ✓ Remote ON/OFF control
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRSDW20UW Series
-
Power Rating20 Watt
-
Output Voltage12 Volt
-
Rated Current1.67 Ampere
-
Input Voltage8.5V~160V
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~95°C
-
Warranty3 Year
-
Length2 in
-
Width1 in
-
Height0.4 in
-
Weight0.06 lb
