Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well RCP-1600-24 power supply 1600W 24V 67A
$515.18 USD
Unit price /
Unavailable
Description
Description
Features
| Universal AC input / Full range |
| Built-in active PFC function |
| High efficiency up to 93% |
| Forced air cooling by built-in DC fan |
| Output voltage and constant current level programmable |
| Built-in OR-ing FET, support hot swap (hot plug) |
| Active current sharing up to 8000W (3 units) in one 19" rack shelf |
| Built-in I²C interface, PMBus protocol |
| Protections: Short circuit / Over current / Over voltage / Over temperature |
| Optional conformal coating |
| 5 years warranty |
General Specification
| AC input voltage range | 90~264VAC | 127 ~ 370VDC |
| DC adjustment range | ±3% rated output voltage |
| Overload protection | 105%~115% constant current limiting, auto-recovery |
| Over-voltage protection | 110%~135% rated output voltage |
| Setup, rise, hold up time | 1500ms, 60ms/230VAC at full load |
| Withstand voltage | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC (0.5KVAC for 12V) |
| Working temperature | -20~+70°C (refer to output derating curve) |
| Safety standards | UL62368-1, CAN/CSA C22.2 , TUV EN62368-1 EAC TP TC 004 approved |
| EMC standards | EN55022 class B, EN61204-3, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 heavy industry level |
| Dimension (LxWxH) (mm) | 300 x 85 x 41 mm |
| Packing | 1.87Kg; 6pcs/12.2Kg/1.16CUFT |
| CASE: | 952A |
Specifications
Specifications
-
BrandMean Well
-
SeriesRCP Series
-
Power Rating1608 Watt
-
Output Voltage24 Volt
-
Rated Current67 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty5 Year
-
Length11.81 in
-
Width3.35 in
-
Height1.61 in
-
Weight4.12 lb
