Mean Well PLD-16-350A Power Supply 16W 350mA

Name: Mean Well PLD-16-350A Power Supply 16W 350mA
Brand: Mean Well
SKU: PLD-16-350A
Price: 19.09 USD
Availability: InStock

plastic caseIP42Class II design without FG

SKU PLD-16-350A

$19.09 USD

Shipping calculated at checkout.

Available to order

Overview

PLD-16-350A is the model of this series: rated current 350mA, rated power 16.8W, typical efficiency 84.5%.

Features

115VAC or 230VAC models available
Built-in active PFC function
Constant current design
Protections: Short circuit / Over temperature
Cooling by free air convection
Fully isolated plastic case
Class 2 Power Unit
Class Ⅱ power unit, no FG
IP42 design
Suitable for LED related fixture or appliance (such as LED Decoration or Advertisement devices)
100% full load burn-in test
Low cost
High reliability
3 years warranty

Specifications

PLD-16-350ASpecifications from the official datasheet (2024-09-25 edition)

OUTPUT

RATED CURRENT: 350mA
OPERATING VOLTAGE RANGE: 24 ~ 48V
CURRENT ACCURACY: ±5.0%
RATED POWER: 16.8W
RIPPLE & NOISE (max.)^Note.1: 4.6Vp-p
NO LOAD OUTPUT VOLTAGE (max.): 60V
SETUP TIME: 500ms / 230VAC 2000ms / 115VAC at full load

INPUT

FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF>0.9/115VAC, PF>0.9/230VAC, PF>0.9/277VAC at full load (Please refer to "Power Factor Characteristic" curve)
TOTAL HARMONIC DISTORTION A series: THD< 20% when output loading≧70% at 115VAC
TOTAL HARMONIC DISTORTION B series: THD< 20% when output loading≧70% at 230VAC input and output loading≧80% at 277VAC input
EFFICIENCY (Typ.) A series: 84.5%
EFFICIENCY (Typ.) B series: 85.5%
AC CURRENT (Typ.): 0.4A/115VAC 0.2A/230VAC 0.15A/277VAC
INRUSH CURRENT(Typ.): COLD START 20A(twidth=25μs measured at 50% Ipeak) at 230VAC
MAX. No. of PSUs on 16A CIRCUIT BREAKER A series: 58 units (circuit breaker of type B) / 58 units (circuit breaker of type C) at 115VAC
MAX. No. of PSUs on 16A CIRCUIT BREAKER B series: 128 units (circuit breaker of type B) / 128 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT: <0.5mA / 240VAC

PROTECTION

SHORT CIRCUIT: Hiccup mode, recovers automatically after fault condition is removed.
OVER TEMPERATURE: Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.: -30 ~ +50℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750,CSA C22.2 No.250.0-08;ENEC BS EN/EN 613471-1,BS EN/EN 61347-2-13 independent, BS EN/EN62384(for B type only), EAC TP TC 004, IP42 approved
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC
ISOLATION RESISTANCE: I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55015 (B type only), BS EN/EN61000-3-2 Class C ; BS EN/EN61000-3-3, FCC part 18 non-consumer equipment(A type only), EAC TP TC 020
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN61547, light industry level, EAC TP TC 020

OTHERS

MTBF: 6807.7K hrs min. Telcordia SR-332 (Bellcore) ; 872.4Khrs min. MIL-HDBK-217F (25℃)
DIMENSION: 84*57*29.5mm (L*W*H)
PACKING: 0.19Kg; 72pcs/14.7Kg/0.92CUFT

Test conditions and notes5

1. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
2. Direct connecting to LEDs is suggested, but is not suitable for using additional drivers.
3. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED power supply can only be used behind a switch without permanently connected to the mains.
4. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
5. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf

Technical drawings

PLD-16-350A Mechanical Specification — Mechanical Specification

PLD-16-350A Block Diagram — Block Diagram

PLD-16-350A Power Factor Characteristic — Power Factor Characteristic

PLD-16-350A EFFICIENCY vs LOAD (PLD-16-350) — EFFICIENCY vs LOAD (PLD-16-350)

Downloads

Certificates5

ENEC Certificate (PLD-16)(EN) PDF Download

CB Certificate (PLD-16)(EN) PDF Download

EMC Certificate (PLD-16)(EN) PDF Download

UL Certificate (PLD-16)(EN) PDF Download

FCC Certificate(PLD-16)(EN) PDF Download

Test reports1

Test Report(PLD-16-350A)(EN) PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can I use the PLD-16-350A for a higher-voltage LED downlight array?

Yes, if the downlight array is designed for 350mA constant current operation. The full LED load must stay within the 24-48V constant current range and within the 16.8W rating.

Is this driver suitable for signage modules that use a longer constant current LED string?

It can be suitable when the signage module string is designed for 350mA constant current. The total forward voltage must remain within 24-48V, and the exact number of LEDs depends on the forward voltage of each LED.

Can the PLD-16-350A run a small LED array with more series voltage than low-voltage drivers?

Yes, this model supports a 24-48V constant current range at 350mA. That makes it a better fit for small LED arrays with a higher total forward voltage than drivers limited to 8-12V or 12-16V.

Can I use this for constant voltage LED strips or tape lighting?

No, the PLD-16-350A is a constant current driver rated at 350mA. It is intended for LED loads that operate within the 24-48V CC range, not for constant voltage strip lighting products.

How do I check compatibility with the PLD-16-350A?

Your LED load must require 350mA constant current and have a total forward voltage between 24V and 48V. The number of LEDs that can be used depends on each LED forward voltage, so the load must be evaluated as a complete series string or array.

Is this driver appropriate for protected indoor environments with temperature swings?

Yes, it is rated for operation from -30°C to +50°C (see the derating curve) and has IP42 protection. That makes it better suited to indoor or otherwise protected locations rather than direct weather exposure.
