Mean Well

Mean Well MPS-65-13.5 Power Supply 65W 13.5V 4.7A

SKU MPS-65-13.5
$46.53 USD
Shipping calculated at checkout.
Available to order
|

Overview

MPS-65-13.5 is the 13.5V output model of this series: rated current 4.7A, rated power 63.45W, typical efficiency 78%.

Features

  • Universal AC input / Full range
  • Low leakage current <250μA
  • Protections: Short circuit / Overload / Over voltage
  • Cooling by free air convection
  • Medical safety approved (2 x MOPP between primary to secondary)
  • 100% full load burn-in test
  • Fixed switching frequency at 45KHz
  • 3 years warranty

Specifications

MPS-65-13.5Specifications from the official datasheet (2021-09-15 edition)

OUTPUT

DC VOLTAGE
13.5V
RATED CURRENT
4.7A
CURRENT RANGE
0 ~ 5.4A
RATED POWER
63.45W
OUTPUT POWER (max.)
72W(+3.3V:50W;+5V:69W)with 18CFM min. Forced air convection
RIPPLE & NOISE (max.)Note.2
100mVp-p
VOLTAGE ADJ. RANGE
12.2 ~ 14.85V
VOLTAGE TOLERANCENote.3
±2.0%
LINE REGULATION
±1.0%
LOAD REGULATION
±2.0%
SETUP, RISE TIME
800ms, 30ms/230VAC 800ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.)
50ms/230VAC 16ms/115VAC at full load

INPUT

VOLTAGE RANGE
90 ~ 264VAC 127 ~ 370VDC
FREQUENCY RANGE
47 ~ 63Hz
EFFICIENCY(Typ.)
78%
AC CURRENT (Typ.)
1.6A/115VAC 0.9A/230VAC
INRUSH CURRENT (Typ.)
COLD START 17A/115VAC 40A/230VAC
LEAKAGE CURRENTNote.7
Earth leakage current < 250μA/264VAC , Touch current < 60μA/264VAC

PROTECTION

OVERLOAD
73 ~ 105W (3.3V:51 ~ 75W)(5V:70 ~ 105W) rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
15.5 ~ 18.2V Protection type : Hiccup mode, recovers automatically after fault condition is removed

ENVIRONMENT

WORKING TEMP.
-10 ~ +60℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-20 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.04%/℃ (0 ~ 50℃)
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC (Note 4)

SAFETY STANDARDS
ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved
ISOLATION LEVEL
Primary-Secondary: 2xMOPP, Primary-Earth:1xMOPP
WITHSTAND VOLTAGE
I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE
I/P-O/P, I/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to EN55011 (CISPR11) Class B, EN61000-3-2,-3
EMC IMMUNITY
Compliance to EN61000-4-2,3,4,5,6,8,11, EN60601-1-2, medical level, criteria A

OTHERS

MTBF
359.7Khrs min. MIL-HDBK-217F (25℃)
DIMENSION
127*76*42mm (L*W*H)
PACKING
0.23Kg; 54pcs/14.6Kg/1.28CUFT
Test conditions and notes7
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com)
  5. 5. Mounting holes M1 and M2 should be grounded for EMI purposes.
  6. 6. Heat Sink HS1,HS2 can not be shorted.
  7. 7. Touch current was measured from primary input to DC output.

Technical drawings

MPS-65-13.5 Mechanical Specification
Mechanical Specification
MPS-65-13.5 Block Diagram
Block Diagram
MPS-65-13.5 Derating Curve
Derating Curve

Downloads

FAQ

Can I use the MPS-65-13.5 for a 13.5V industrial control panel or alarm enclosure?

It can fit 13.5V industrial or control-panel loads that need constant-voltage output and stay within 4.7A and 63.45W. Its universal 90-264VAC input also helps when the AC source may vary by site. Check that the connected equipment is specified for 13.5V DC, not 12V or 15V.

Is this power supply suitable for 13.5V communications or monitoring equipment?

This model is intended for equipment that requires a regulated 13.5V DC supply and draws no more than 4.7A. That makes it a practical fit for low-power communications, monitoring, or signal-processing hardware designed around 13.5V constant voltage. The available output power is 63.45W.

Can the MPS-65-13.5 power embedded electronics or bench test fixtures that run on 13.5V?

Yes, if the embedded assembly or test fixture needs constant 13.5V DC and the total load remains within 4.7A and 63.45W. The compact 127.0 x 76.0 x 42.0 mm housing can also matter where space is limited. Verify the device's rated input voltage before selecting it.

How does the MPS-65-13.5 compare with the other MPS-65 output options?

Within the MPS-65 range, the options are 3.3V 12A 39.6W, 5V 12A 60W, 7.5V 8A 60W, 12V 5.2A 62.4W, 13.5V 4.7A 63.45W, 15V 4.2A 63W, 24V 2.7A 64.8W, 27V 2.4A 64.8W, and 48V 1.35A 64.8W. The main difference is the output voltage and matching current capacity for each version. This specific model is the 13.5V variant rated at 4.7A.

Is the MPS-65-13.5 suitable for outdoor or harsh-environment use?

The provided specs list an operating temperature of -10°C to +60°C, but no IP rating is given. Based on that spec set, it is better treated as a power supply for protected indoor equipment rather than an exposed outdoor location. If your application needs dust or water resistance, the listing does not state that for this model.
