Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well MPS-120-5 Power Supply 110W 5V he rated current is based ...
$103.20 USD
Unit price /
Unavailable
Description
Description
MEAN WELL MPS-120 Series Power Supplies are 120W singlel output medical type power supplies with 3 years warranty.
Features
- Universal AC/Full range
- Low leakage current<180uA
- Protections:Shortzircuit/Overload/Over voltage
- UL60601-1 medical safety approved
- With power good and fail signal outputOptional)
- 100% full load burn in test
- Fixed switching frequency at 45KHz
- 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesMPS Series
-
Power Rating110 Watt
-
Output Voltage5 Volt
-
Rated Current22 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length7 in
-
Width4.25 in
-
Height1.4 in
-
Weight1.21 lb
