Mean Well MDS02N-15N SIP Package DC-DC Converter- 2W - 15V Out

$6.29 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

MDS - MDD

Features:

  • SIP7 package with international standard pinout
  • Operating temperature range -40 ~ +95°C
  • Comply with IEC/UL62368-1 (Expect for 15Vo/±15Vo) and LVD IEC60601-1
  • Medical safety approved (1xMOPP/2xMOOP) according to IEC60601-1
  • Low patient leakage current <2μA
  • Protections: Short circuit (Continuous)
  • 6KVDC hight I/O isolation (Reinforced insulation)
  • Low cost
  • 3 years warranty

General Specification

Input Voltage (Vdc)

5V (4.5 ~ 5.5V) | 12V (10.8 ~ 13.2V) | 24 (21.6 ~ 26.4V)

Output Voltage (Vdc)

1 Vo: 3.3V / 5V / 12V / 15V

2 Vo: ±5V / ±12V / ±15V

Overload Protection

Shut down the output when rated power≥102%, auto recovers

Operating Temperature

-40 ~ + 95°C

Short Circuit Protection

Continuous protection for a long time

Safety Certificate

CB / UL / EAC / CE / UKCA (62368-1 + 60601-1)

Dimension (LxWxH)

19.7 x 7.1 x 11.5 mm

Specifications

  • Brand
    Mean Well
  • Series
    MDS Series
  • Power Rating
    2 Watt
  • Output Voltage
    15 Volt
  • Rated Current
    0.01 Ampere
  • Input Voltage
    21.6V~26.4V
  • Standards Met
    CB,CE,EAC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~95°C
  • Warranty
    3 Year
  • Length
    0.78 in
  • Width
    0.28 in
  • Height
    0.45 in
  • Weight
    0.01 lb

File Downloads
