Mean Well LPV-100-36 LED Driver — 100.8W 36V 2.8A IP67 Waterproof

Name: Mean Well LPV-100-36 LED Driver — 100.8W 36V 2.8A IP67 Waterproof
Brand: Mean Well
SKU: LPV-100-36
Price: 30.25 USD
Availability: InStock

$30.25 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

The Mean Well LPV-100-36 is a 100.8W, 36V constant voltage LED driver with IP67 waterproof protection, engineered for reliable performance in demanding indoor and outdoor LED lighting applications. Built to Mean Well's industry-leading quality standards, it delivers stable 36V DC output at up to 2.8A and carries CE, EAC, UL certifications for global compliance.

Accepting 90-264VAC universal AC input, the LPV-100-36 operates reliably across a wide supply range. It features built-in short circuit, overload, and over-voltage protection to safeguard connected LED loads, and is rated for operation from -25°C to +70°C making it suitable for outdoor and harsh-environment installations.

Key Features

✓Constant voltage output: 36V DC at up to 2.8A (100.8W max)
✓IP67 waterproof and dustproof — suitable for outdoor installations
✓Universal AC input: 90-264VAC
✓Certifications: CE, EAC, UL
✓Wide operating temperature: -25°C to +70°C
✓Built-in protections: short circuit, overload, over-voltage
✓Compact, lightweight enclosure: 190.0 × 52.0 × 37.0 mm, 0.61 kg
✓2-year Mean Well warranty

Specifications

Brand

Mean Well
Series

LP Series
Power Rating

100.8 Watt
Output Voltage

36 Volt
Rated Current

2.8 Ampere
Input Voltage

90V~264V
Standards Met

CE,EAC,UL
Operation Mode

Constant Voltage
Operating Temperature

-25°C~70°C
Warranty

2 Year
Length

7.48 in
Width

2.05 in
Height

1.46 in
Weight

1.34 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

{ "id":8649435513152, "variants" :[{ "context":"default", "variant_id": 46610154586432, "sku":"LPV-100-36", "inventory_qty" : 103, "customer" : true, "custom_html" :"\u003cdiv class=\"price\"\u003e\n \u003cdiv class=\"price__default\"\u003e\n \u003cstrong class=\"price__current\"\u003e$30.25\u003c\/strong\u003e\n \u003cs class=\"price__was\"\u003e\u003c\/s\u003e\n \u003c\/div\u003e\n\n \u003cdiv class=\"unit-price relative\" hidden\u003e\u003cspan class=\"visually-hidden\"\u003eUnit price\u003c\/span\u003e\u003cspan class=\"unit-price__price\"\u003e\u003c\/span\u003e\u003cspan class=\"unit-price__separator\"\u003e \/ \u003c\/span\u003e\u003cspan class=\"unit-price__unit\"\u003e\u003c\/span\u003e\u003c\/div\u003e\n\n \u003cdiv class=\"price__no-variant\" hidden\u003e\n \u003cstrong class=\"price__current\"\u003eUnavailable\u003c\/strong\u003e\n \u003c\/div\u003e\n\n \u003c\/div\u003e\n", "volume_html" :"\u003cvolume-pricing class=\"parent-display inside_product_form\" id=\"volume-pricing-main\" \u003e\u003c\/volume-pricing\u003e" } ] }

Key Features

✓Constant voltage output: 36V DC at up to 2.8A (100.8W max)

✓IP67 waterproof and dustproof — suitable for outdoor installations

✓Universal AC input: 90-264VAC

✓Certifications: CE, EAC, UL

✓Wide operating temperature: -25°C to +70°C

✓Built-in protections: short circuit, overload, over-voltage

✓Compact, lightweight enclosure: 190.0 × 52.0 × 37.0 mm, 0.61 kg

✓2-year Mean Well warranty
