Description
Description
The Mean Well LCM-40U is a 35W constant current LED driver with a selectable output current, so one part number covers a range of luminaire builds. Output is set by DIP switch, removing the need to stock a separate driver per current.
It accepts 90~132VAC input and is rated from -30°C to 90°C and carries FCC approval. It supports 0-10V, 10V PWM and resistance dimming. Backed by a 3-year warranty.
Key Features
- ✓Constant Current mode output with multiple levels selectable by dip switch
- ✓Plastic housing with Class II design
- ✓Built-in active PFC function
- ✓Functions: 3 in 1 dimming (dim-to-off); Auxiliary DC output; synchronization up to 10 units
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesLCM Series
-
Power Rating35 Watt
-
Output Voltage65 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~132V
-
Standards MetFC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~90°C
-
Warranty3 Year
-
Length4.86 in
-
Width3.21 in
-
Height0.91 in
-
Weight0.62 lb
