Mean Well IRM-01-24S Switching Power Supply 1W 24V 72mA - Encapsulated | IRM Series

Name: Mean Well IRM-01-24S Switching Power Supply 1W 24V 72mA - Encapsulated
Brand: Mean Well
SKU: IRM-01-24S
Price: 7.63 USD
Availability: InStock

Overview

IRM-01-24S is the 24V output model of this series: rated current 42mA, rated power 1W, typical efficiency 77%.

IRM-01 is a 1W miniature (33.7*22.2*15mm) AC-DC module-type power supply, ready to be soldered onto the PCB boards of various kinds of electronic instruments or industrial automation equipments. This product allows a universal input voltage range of 85~305VAC. The phenolic case and the fully-potted silicone enhance the heat dissipation and meet the anti-vibration demand up to 5G; moreover, it provides the fundamental resistance to dust and moisture. With the high efficiency up to 77% and the extremely low no-load power consumption below 0.075W, IRM-01 series fulfills the worldwide regulation for the low power consumption requirement for electronics. The entire series is a Class Ⅱ design (no FG pin), incorporating the built-in EMI filtering components, enabling the compliance with EN55032 Class B; the supreme EMC features keep the end electronic units from electromagnetic interference. In addition to module-type model, IRM-01 series also offers the SMD style model.

Features

Universal AC input / Full range
No load power consumption<0.075W
Compact size
Comply with EN55032 Class B without any additional components
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Isolation ClassⅡ
High reliability, low cost
3 years warranty

Specifications

IRM-01-24SSpecifications from the official datasheet (2020-10-12 edition)Download datasheet PDF

OUTPUT

DC VOLTAGE: 24V
RATED CURRENT: 42mA
CURRENT RANGE: 0 ~ 42mA
RATED POWER: 1W
RIPPLE & NOISE (max.)^Note.2: 200mVp-p
VOLTAGE TOLERANCE^Note.3: ±2.5%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±0.5%
SETUP, RISE TIME: 600ms, 30ms/230VAC 600ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.): 40ms/230VAC 12ms/115VAC at full load

INPUT

VOLTAGE RANGE: 85 ~ 305VAC 120 ~ 430VDC
FREQUENCY RANGE: 47 ~ 63Hz
EFFICIENCY (Typ.): 77%
AC CURRENT (Typ.): 25mA/115VAC 18mA/230VAC 16mA/277VAC
INRUSH CURRENT (Typ.): 5A/115VAC 10A/230VAC
LEAKAGE CURRENT: < 0.25mA/277VAC

PROTECTION

OVERLOAD: ≥110% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE: 25.2 ~ 32.4V Protection type : Shut off o/p voltage, clamping by zener diode

ENVIRONMENT

WORKING TEMP.: -30 ~ +85℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +100℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 75℃)
VIBRATION: 10 ~ 500Hz, 5G 10min./1cycle, period for 60min. each along X, Y, Z axes
LEAD TEMPERATURE: 260℃,10s (max.)

SAFETY & EMC

SAFETY STANDARDS: UL62368-1, TUV EN62368-1, EAC TP TC 004 , BSMI CNS14336-1 approved , Design refer to EN61558-1/-2-16
WITHSTAND VOLTAGE: I/P-O/P:3KVAC
ISOLATION RESISTANCE: I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3, EAC TP TC 020, CNS13438 Class B
EMC IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level (surge L-N : 1KV), criteria A, EAC TP TC 020

OTHERS

MTBF: 1960Khrs min. MIL-HDBK-217F (25℃)
DIMENSION: PCB mounting style : 33.7*22.2*15mm (L*W*H) SMD style : 33.7*22.2*16mm (L*W*H)
PACKING: PCB mounting style : 0.024Kg; 640pcs/ 16.3 Kg/ 0.84CUFT SMD style : 0.024Kg; 640 pcs/ 16.3 Kg/ 0.84CUFT

Test conditions and notes4

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

IRM-01-24S Block Diagram — Block Diagram

IRM-01-24S Mechanical Specification — Mechanical Specification

IRM-01-24S Recommended PCB Layout (for SMD — Recommended PCB Layout (for SMD

Typical applications

Industrial electrical equipment
Mechanical equipment
Factory automation equipment
Handheld electronic device

Downloads

Datasheet1

IRM-01-24S datasheetIRM-01-SPEC.PDF · 2020-10-12 edition PDF Download

Certificates4

EMC Certificate (IRM-01)(EN) PDF Download

UL Certificate (IRM-01)(EN) PDF Download

CB Certificate (IRM-01)(EN) PDF Download

TUV Certificate (IRM-01)(EN) PDF Download

Test reports1

Test Report (IRM-01-24)(EN) PDF Download

Catalogues1

Mean Well Catalog (Industrial) PDF Download

FAQ

Can I use the IRM-01-24S for a small 24V industrial sensor or interface circuit?

Yes, this model is intended for low-power 24V DC loads where 1W is sufficient. It is a constant voltage supply with a 24V output and a wide 85-305VAC input range, which fits compact industrial control or interface electronics rather than higher-draw loads.

Is the IRM-01-24S suitable for embedded 24V control electronics on a compact board?

It can fit compact embedded designs because the package is 33.7 × 22.2 × 16.0 mm and the unit is described as a miniature encapsulated type with SMD style. The 24V constant voltage output and 1W power level make it appropriate for very small onboard power sections, not larger 24V subsystems.

Can this 24V power supply be used for light automation signaling circuits?

Yes, if the automation circuit needs a regulated 24V DC source and stays within the 1W rating. This model is better suited to low-consumption signaling, sensing, or control electronics than to devices that need more output power.

Is the IRM-01-24S okay for outdoor or harsh-temperature use?

The operating temperature range is -30°C to +85°C, so it covers a wide temperature span. No IP rating is listed, so it should be treated as a protected internal power module rather than a supply for exposed outdoor or wet locations.

How does the IRM-01-24S compare with other Mean Well IRM encapsulated models?

Within the 1W IRM-01 group, related options are IRM-01-3.3 and IRM-01-3.3S at 3.3V 300A, IRM-01-5 and IRM-01-5S at 5V 200A, IRM-01-9 and IRM-01-9S at 9V 111A, IRM-01-12 and IRM-01-12S at 12V 0.08A, IRM-01-15 and IRM-01-15S at 15V 0.07A, and IRM-01-24 and IRM-01-24S at 24V 0.04A. Higher-power IRM siblings then step up through IRM-02, IRM-03, IRM-05, IRM-10, IRM-15, IRM-20, IRM-30, IRM-45, IRM-60, and IRM-90 variants, covering outputs from 3.3V to 48V and power levels from 2W to 90.2W.
