Mean Well

Mean Well IRM-01-12 Switching Power Supply 1W 12V 83mA - Encapsulated

miniature encapsulated typePCB mouting style
SKU IRM-01-12
$7.25 USD
Shipping calculated at checkout.

Select model — 18 in this family

IRM-01-12
In stock
|

Overview

IRM-01-12 is the 12V output model of this series: rated current 83mA, rated power 1W, typical efficiency 74%.

IRM-01 is a 1W miniature (33.7*22.2*15mm) AC-DC module-type power supply, ready to be soldered onto the PCB boards of various kinds of electronic instruments or industrial automation equipments. This product allows a universal input voltage range of 85~305Vac. The phenolic case and potted with silicone enhance the heat dissipation and meet the anti-vibration demand up to 5G; moreover, it provides the fundamental resistance to dust and moisture. With the high efficiency up to 77% and the extremely low no-load power consumption below 0.075W, IRM-01 series fulfills the worldwide regulation for the low power consumption requirement for electronics. The entire series is a Class Ⅱ design (no FG pin), incorporating the built-in EMI filtering components, enabling the compliance with BS EN/EN55032 Class B; the supreme EMC features keep the end electronic units from electromagnetic interference.

Features

  • Universal AC input / Full range
  • No load power consumption<0.075W
  • Compact size
  • Comply with BS EN/EN55032 Class B without any additional components
  • Wide operating temp. range -30~+85℃
  • Protections: Short circuit / Overload / Over voltage
  • Cooling by free air convection
  • Isolation ClassⅡ
  • High reliability, low cost
  • 3 years warranty

Specifications

IRM-01-12Specifications from the official datasheet (2026-07-01 edition)

OUTPUT

DC VOLTAGE
12V
RATED CURRENT
83mA
CURRENT RANGE
0 ~ 83mA
RATED POWER
1W
RIPPLE & NOISE (max.)Note.2
150mVp-p
VOLTAGE TOLERANCENote.3
±2.5%
LINE REGULATION
±0.5%
LOAD REGULATION
±0.5%
SETUP, RISE TIME
600ms, 30ms/230Vac 600ms, 30ms/115Vac at full load
HOLD UP TIME (Typ.)
40ms/230Vac 12ms/115Vac at full load

INPUT

VOLTAGE RANGE
85 ~ 305Vac 120 ~ 430Vdc
FREQUENCY RANGE
47 ~ 63Hz
EFFICIENCY (Typ.)
74%
AC CURRENT (Typ.)
25mA/115Vac 18mA/230Vac 16mA/277Vac
INRUSH CURRENT (Typ.)
5A/115Vac 10A/230Vac
LEAKAGE CURRENT
< 0.25mA/277Vac

PROTECTION

OVERLOAD
≥110% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
12.6 ~ 16.2V Protection type : Shut off o/p voltage, clamping by zener diode

ENVIRONMENT

WORKING TEMP.
-30 ~ +85℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-40 ~ +100℃, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03%/℃ (0 ~ 75℃)
VIBRATION
10 ~ 500Hz, 5G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS
IEC62368-1,IEC61558-1/-2-16,UL62368-1,TUV BS EN/EN62368-1,BS EN/EN61558-1/-2-16,EAC TP TC 004 , BSMI CNS15598-1 approved
OVER VOLTAGE CATEGORY
IEC/EN 61558-1/-2-16(OVC Ⅱ, altitude up to 2000m); IEC/EN/UL 62368-1(OVC Ⅱ, altitude up to 2000m)
WITHSTAND VOLTAGE
I/P-O/P:4.2KVac
ISOLATION RESISTANCE
I/P-O/P:100M Ohms / 500Vdc / 25℃/ 70% RH
EMC EMISSION
Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020, CNS15936 Class B
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, heavy industry level (surge L-N : 1KV), EAC TP TC 020

OTHERS

MTBF
13571.4K hrs min. Telcordia SR-332 (Bellcore) ; 1960.2K hrs min. MIL-HDBK-217F (25℃)
DIMENSION
33.7*22.2*15mm (L*W*H)
PACKING
0.024Kg; 640pcs/ 16.3 Kg/ 0.84CUFT
Test conditions and notes4
  1. 1. All parameters NOT specially mentioned are measured at 230Vac input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

IRM-01-12 Block Diagram
Block Diagram
IRM-01-12 Derating Curve
Derating Curve

Typical applications

  • Industrial electrical equipment
  • Mechanical equipment
  • Factory automation equipment
  • Handheld electronic device

Downloads

FAQ

Can I use the IRM-01-12 for a small 12V industrial control circuit?

Yes, if the control circuit needs a constant 12V DC supply and stays within the 1W, 83mA output limit. It is a better fit for low-power industrial monitoring, interface, or control electronics than for heavier 12V loads.

Is the IRM-01-12 suitable for an embedded 12V sensor or alarm board?

It can work for compact embedded 12V boards that use constant voltage and draw no more than 83mA from a 1W supply. The miniature encapsulated design and 33.7 × 22.2 × 15.0 mm size also suit tight board-level space.

Can this power a low-draw 12V auxiliary rail in IT or telecom equipment?

It is appropriate for very low-power 12V auxiliary rails where the load stays within 1W and 83mA. Buyers should treat it as a small constant voltage supply for board-level support functions, not for higher-current 12V equipment.

How does the IRM-01-12 compare with other low-power IRM models?

In the 1W IRM-01 series, sibling outputs are 3.3V 300mA, 5V 200mA, 9V 111mA, 12V 83mA, 15V 67mA, and 24V 42mA, all in the same 33.7 × 22.2 × 15 mm encapsulated package with 85-305VAC input. The IRM-01-12 has 74% typical efficiency and 150mVp-p max. ripple; if you need more than 1W at 12V, a higher-power supply is required.

Is the IRM-01-12 suitable for outdoor or harsh-temperature use?

The operating temperature range is -30°C to +85°C, with output derating at higher ambient temperatures per the derating curve. An IP rating is not listed, so indoor or outdoor exposure suitability is not specified by the provided specs.
