Description
Description
Features
Universal AC input (up to 305VAC) / Full range |
High efficiency up to 95% |
Built-in active PFC function, PF> 0.9 for 60% of load or higher |
Protections: Short circuit / Over current / Over voltage / Over temperature |
IP67 / IP65 design for indoor or outdoor installations |
Cooling by free air convection |
Output current adjustable |
Suitable for LED lighting and street lighting applications |
Meet 4kV surge immunity level (IEC61000-4-5) |
Multiple models for choice: A-Type: IP65 rated. Output voltage and constant current level can be adjusted through internal potentiometer B-Type: IP67 rated and built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance) C-Type: Terminal block for I/O connection Blank-Type: IP67 rated. Cable for I/O connection D-Type(option): IP67 rated. Timer dimming function, contact MEAN WELL for details (safety pending for 150~240W) |
7 years warranty |
General Specification
AC input voltage range | 90~305VAC ; 127~431VDC |
AC inrush current (max.) | Cold start, 70A at 230VAC |
DC adjustment range | ±6% rated output voltage |
Current adjustment range | 50%~100% |
Over current protection | 95%~108% constant current limiting, auto-recovery |
Over voltage protection | 110%~140% rated output voltage |
Setup, rise, hold up time | 2500ms, 80ms, 15ms at full load and 230VAC |
Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
Working temperature | -40~+70ºC (refer to output derating curve) |
Safety standards | UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 (except for C-Type) approved; UL1012, UL60950-1 |
EMC standards | EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 |
Connection Input | UL rated, SJTW 18AWGx3C (30cm); |
Connection Output | A/D/Blank-Type: SJTW 14AWGx2C (30cm) ; B-Type: SJTW 14AWGx2C (30cm)+SJTW 18AWGx2C (30cm); C-Type: Terminal block |
Dimension (LxWxH) (mm) | 252x 90x 43.8 |
Specifications
Specifications
-
BrandMean Well
-
SeriesHLG-C Series
-
Power Rating319.2 Watt
-
Output Voltage156 Volt
-
Rated Current2.1 Ampere
-
Input Voltage90V~305V
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty7 Year
-
Length9.92 in
-
Width3.54 in
-
Height1.72 in
-
Weight4.14 lb
