Mean Well HLG-240H-C700B | Constant Current LED Driver

Name: Mean Well HLG-240H-C700B Power Supply 249.9W 700mA - Dimmable
Brand: Mean Well
SKU: HLG-240H-C700B
Price: 75.56 USD
Availability: InStock

Overview

HLG-240H-C700B is the model of this series: rated current 700mA, rated power 249.9W, typical efficiency 93.5%. Type B: 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance) (IP67).

HLG-240H-C series is a 250W LED AC/DC LED driver featuring the constant current mode and high voltage output. HLG-240H-C operates from 90~305VAC and offers models with different rated current ranging between 700mA and 2100mA. Thanks to the high efficiency up to 94%, with the fanless design, the entire series is able to operate for -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-240H-C is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Features

Constant current mode output
Metal housing with ClassⅠdesign
Built-in active PFC function
IP67 design for indoor or outdoor installations
Function options: 3 in 1 dimming
Typical lifet ime>62000 hours
7 years warranty

Specifications

HLG-240H-C700BSpecifications from the official datasheet (2026-02-04 edition)

OUTPUT

RATED CURRENT: 700mA
RATED POWER: 249.9W
CONSTANT CURRENT REGION^Note.2: 178 ~ 357V
OPEN CIRCUIT VOLTAGE (max.): 360V
CURRENT ADJ. RANGE: 350 ~ 700mA
CURRENT RIPPLE: 5.0% max. @rated current
CURRENT TOLERANCE: ±5%
SET UP TIME^Note.4: 1000ms/115VAC, or 500ms/230VAC

INPUT

VOLTAGE RANGE^Note.3: 90 ~ 305VAC 127 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC @full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION: THD< 20% (@ load≧50% /115VAC, 230VAC; @ load≧75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION (THD)” section)
EFFICIENCY (Typ.): 93.5%
AC CURRENT (Typ.): 2.5A / 115VAC 1.3A / 230VAC 1.1A / 277VAC
INRUSH CURRENT(Typ.): COLD START 75A(twidth=700μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER: 2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT: <0.75mA / 277VAC

PROTECTION

SHORT CIRCUIT: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 375 ~ 410V Shut down and latch off o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.: Tcase=-40 ~ +90℃(Refer to "Derating Curve")
MAX. CASE TEMP.: Tcase=+90℃
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750(type”HL”), CSA C22.2 No. 250.13-12; BS EN/EN/AS/NZS 61347-1, BS EN/EN/AS/NZS 61347-2-13, BS EN/EN62384 independent; GB/T19510.1,GB/T19510.213; IP67, EAC TP TC 004 approved
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (@ load≧50%) ; BS EN/EN61000-3-3,GB/T 17743 , GB17625.1, EAC TP TC 020
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN61547, light industry level (surge immunity Line-Earth 4KV, Line-Line 2KV),EAC TP TC 020

OTHERS

MTBF: 2513.7K hrs min. Telcordia SR-332 (Bellcore) ; 228.5K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 244.2*68*38.8mm (L*W*H)
PACKING: 1.3Kg; 12pcs/16.6Kg/0.84CUFT

Certifications & ratings

Type: HL

MODEL ENCODING

A: Io adjustable through built-in potentiometer; IP65
B (this model): 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP67
AB: Io adjustable through built-in potentiometer & 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP65
DX: Built-in Smart timer dimming function by user request; IP67
D2: Built-in Smart timer dimming and programmable function; IP67

Test conditions and notes10

1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
2. Please refer to "DRIVING METHODS OF LED MODULE".
3. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
4. Length of set up time is measured at first cold start. Turning ON/OFF the driver may lead to increase of the set up time.
5. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
6. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED driver can only be used behind a switch without permanently connected to the mains.
7. This series meets the typical life expectancy of >62,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 75℃ or less.
8. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com.
9. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
10. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf

Technical drawings

HLG-240H-C700B BLOCK DIAGRAM — BLOCK DIAGRAM

HLG-240H-C700B DIMMING OPERATION — DIMMING OPERATION

HLG-240H-C700B Illustration (page 5) — Illustration (page 5)

HLG-240H-C700B 250W Constant Current Mode LED Driver — 250W Constant Current Mode LED Driver

HLG-240H-C700B OUTPUT LOAD vs TEMPERATURE(Note.8) — OUTPUT LOAD vs TEMPERATURE(Note.8)

HLG-240H-C700B STATIC CHARACTERISTIC — STATIC CHARACTERISTIC

HLG-240H-C700B TOTAL HARMONIC DISTORTION — TOTAL HARMONIC DISTORTION

HLG-240H-C700B LIFETIME(Kh) — LIFETIME(Kh)

HLG-240H-C700B MECHANICAL SPECIFICATION ※ B/D2-Type — MECHANICAL SPECIFICATION ※ B/D2-Type

Typical applications

LED street lighting
LED fishing lamp
LED harbor lighting
LED building architectural lighting
LED bay lighting
Type “HL” for use in ClassⅠ, Division 2 hazardous (Classified) location.

Downloads

Datasheet1

HLG-240H-C700B datasheetHLG-240H-C-SPEC.PDF · 2026-02-04 edition PDF Download

Certificates4

UL Certificate (HLG-240H-C)(EN) PDF Download

CB Certificate (HLG-240H-C)(EN) PDF Download

EMC Certificate (HLG-240H-C)(EN) PDF Download

ENEC Certificate (HLG-240H-C)(EN) PDF Download

Test reports1

Test Report(HLG-240H-C700)(EN) PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can I use the HLG-240H-C700B with a 1-10V dimmer to control high-voltage LED arrays?

Yes. The HLG-240H-C700B includes a dimming signal input and delivers 700mA constant current across a 178-357V range at up to 249.9W. You can pair with a 1-10V or PWM dimming controller to smoothly adjust brightness on compatible high-voltage LED arrays without needing a separate dimming module.

Is the HLG-240H-C700B suitable for driving LED street light or area light fixtures?

Yes. With 249.9W at 700mA constant current and an IP65/IP67-rated series housing, this driver can power outdoor LED area lights designed for high-voltage series LED strings within the 178-357V range. Its wide 90-305VAC input handles international mains voltages, and it operates over a Tcase range of -40°C to +90°C (derating applies at high ambient temperatures).

Can I use the HLG-240H-C700B for architectural LED facade lighting?

Yes, provided your facade luminaires accept 700mA constant-current drive in the 178-357V range. The series is rated IP65 or IP67 depending on type, and the dimming input (1-10VDC, 10V PWM or resistance) allows scene control from a compatible lighting controller. For fully exposed locations, check the rating of your type and follow MEAN WELL's IP installation cautions in the user manual.

Can the HLG-240H-C700B power LED modules for large backlit display panels?

Yes. At 249.9W and 700mA, it can drive high-voltage LED module strings used in large-format backlit displays, light boxes, or illuminated menu boards. The dimming input lets you adjust display brightness to match ambient lighting conditions throughout the day.

What LED forward voltage total should I target when using the HLG-240H-C700B?

Your series LED string's total forward voltage must fall within the 178-357V constant-current range. The exact number of LEDs depends on each LED's forward voltage. For example, if each LED has a 3V forward voltage, a string of roughly 60 to 119 LEDs would be within range, but always verify with your specific LED datasheet.

Can the HLG-240H-C700B handle temperature extremes in outdoor enclosures?

Yes. It is rated for a case temperature (Tcase) of -40°C to +90°C, and the series carries an IP65 or IP67 rating depending on type. This suits cold outdoor cabinets in winter and warm rooftop enclosures, but output must be derated at high ambient temperatures per the derating curve, so ensure adequate ventilation to keep the case at or below +90°C.
