Mean Well HLG-240H-C700AB 249.9W 700mA Power Supply - Adjustable and Dimmable

Name: Mean Well HLG-240H-C700AB Power Supply 249.9W 700mA - Adjustable and Dimmable
Brand: Mean Well
SKU: HLG-240H-C700AB
Price: 81.81 USD
Availability: InStock

Overview

HLG-240H-C700AB is the model of this series: rated current 700mA, rated power 249.9W, typical efficiency 93.5%. Type AB: Io adjustable through built-in potentiometer & 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance) (IP65).

HLG-240H-C series is a 250W LED AC/DC LED driver featuring the constant current mode and high voltage output. HLG-240H-C operates from 90~305VAC and offers models with different rated current ranging between 700mA and 2100mA. Thanks to the high efficiency up to 94%, with the fanless design, the entire series is able to operate for -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-240H-C is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Features

Constant current mode output
Metal housing with ClassⅠdesign
Built-in active PFC function
IP65 design for indoor or outdoor installations
Function options: output adjustable via potentiometer; 3 in 1 dimming
Typical lifet ime>62000 hours
7 years warranty

Specifications

HLG-240H-C700ABSpecifications from the official datasheet (2026-02-04 edition)

OUTPUT

RATED CURRENT: 700mA
RATED POWER: 249.9W
CONSTANT CURRENT REGION^Note.2: 178 ~ 357V
OPEN CIRCUIT VOLTAGE (max.): 360V
CURRENT ADJ. RANGE: Can be adjusted by internal potentiometer (A/AB type only)
CURRENT ADJ. RANGE: 350 ~ 700mA
CURRENT RIPPLE: 5.0% max. @rated current
CURRENT TOLERANCE: ±5%
SET UP TIME^Note.4: 1000ms/115VAC, or 500ms/230VAC

INPUT

VOLTAGE RANGE^Note.3: 90 ~ 305VAC 127 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC @full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION: THD< 20% (@ load≧50% /115VAC, 230VAC; @ load≧75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION (THD)” section)
EFFICIENCY (Typ.): 93.5%
AC CURRENT (Typ.): 2.5A / 115VAC 1.3A / 230VAC 1.1A / 277VAC
INRUSH CURRENT(Typ.): COLD START 75A(twidth=700μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER: 2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT: <0.75mA / 277VAC

PROTECTION

SHORT CIRCUIT: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 375 ~ 410V Shut down and latch off o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.: Tcase=-40 ~ +90℃(Refer to "Derating Curve")
MAX. CASE TEMP.: Tcase=+90℃
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750(type”HL”), CSA C22.2 No. 250.13-12; BS EN/EN/AS/NZS 61347-1, BS EN/EN/AS/NZS 61347-2-13, BS EN/EN62384 independent; GB/T19510.1,GB/T19510.213; IP65, EAC TP TC 004 approved
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (@ load≧50%) ; BS EN/EN61000-3-3,GB/T 17743 , GB17625.1, EAC TP TC 020
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN61547, light industry level (surge immunity Line-Earth 4KV, Line-Line 2KV),EAC TP TC 020

OTHERS

MTBF: 2513.7K hrs min. Telcordia SR-332 (Bellcore) ; 228.5K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 244.2*68*38.8mm (L*W*H)
PACKING: 1.3Kg; 12pcs/16.6Kg/0.84CUFT

Certifications & ratings

Type: HL

MODEL ENCODING

A: Io adjustable through built-in potentiometer; IP65
B: 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP67
AB (this model): Io adjustable through built-in potentiometer & 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP65
DX: Built-in Smart timer dimming function by user request; IP67
D2: Built-in Smart timer dimming and programmable function; IP67

Test conditions and notes11

1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
2. Please refer to "DRIVING METHODS OF LED MODULE".
3. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
4. Length of set up time is measured at first cold start. Turning ON/OFF the driver may lead to increase of the set up time.
5. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
6. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED driver can only be used behind a switch without permanently connected to the mains.
7. This series meets the typical life expectancy of >62,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 75℃ or less.
8. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com.
9. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
10. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf
11. For A/AB type need to consider build in using to comply with Type HL application.

Technical drawings

HLG-240H-C700AB BLOCK DIAGRAM — BLOCK DIAGRAM

HLG-240H-C700AB DIMMING OPERATION — DIMMING OPERATION

HLG-240H-C700AB Illustration (page 5) — Illustration (page 5)

HLG-240H-C700AB 250W Constant Current Mode LED Driver — 250W Constant Current Mode LED Driver

HLG-240H-C700AB OUTPUT LOAD vs TEMPERATURE(Note.8) — OUTPUT LOAD vs TEMPERATURE(Note.8)

HLG-240H-C700AB STATIC CHARACTERISTIC — STATIC CHARACTERISTIC

HLG-240H-C700AB TOTAL HARMONIC DISTORTION — TOTAL HARMONIC DISTORTION

HLG-240H-C700AB LIFETIME(Kh) — LIFETIME(Kh)

HLG-240H-C700AB MECHANICAL SPECIFICATION ※ AB-Type — MECHANICAL SPECIFICATION ※ AB-Type

Typical applications

LED street lighting
LED fishing lamp
LED harbor lighting
LED building architectural lighting
LED bay lighting
Type “HL” for use in ClassⅠ, Division 2 hazardous (Classified) location.

Downloads

Datasheet1

HLG-240H-C700AB datasheetHLG-240H-C-SPEC.PDF · 2026-02-04 edition PDF Download

Certificates4

UL Certificate (HLG-240H-C)(EN) PDF Download

CB Certificate (HLG-240H-C)(EN) PDF Download

EMC Certificate (HLG-240H-C)(EN) PDF Download

ENEC Certificate (HLG-240H-C)(EN) PDF Download

Test reports1

Test Report(HLG-240H-C700)(EN) PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can I use the HLG-240H-C700AB to drive high-voltage LED string arrays for commercial signage?

Yes. The HLG-240H-C700AB delivers a constant 700mA across a CC voltage range of 178-357V, providing up to 249.9W. This makes it well suited for long series strings of LEDs used in large channel letters, billboard backlighting, or illuminated sign cabinets where high-voltage constant-current drive is required.

Is the HLG-240H-C700AB suitable for powering high-bay LED fixtures in a warehouse?

Yes. At 249.9W and 700mA constant current, this driver can power high-bay LED fixtures designed for high-voltage series LED configurations. Its IP65/IP67-rated series housing and -40°C to +90°C case temperature range (with derating at high ambient temperatures) make it suitable for warehouses, factories, and covered industrial environments.

Can I dim the HLG-240H-C700AB and also fine-tune its output?

Yes. The AB suffix means this model includes both an output adjustment potentiometer and a 3-in-1 dimming input (1-10VDC, 10V PWM signal, or resistance). You can use the potentiometer to trim the constant-current output level and the dimming input to control brightness dynamically from an external controller.

Can the HLG-240H-C700AB drive LED grow lights or horticultural lighting panels?

Yes, provided the LED panel is designed for 700mA constant-current drive within the 178-357V range. The built-in dimming input lets you adjust light intensity for different growth stages, and the working humidity rating of 20-95% RH (non-condensing) covers typical greenhouse conditions.

How many LEDs can I run in series with the HLG-240H-C700AB?

The number of LEDs depends on each LED's individual forward voltage. The HLG-240H-C700AB operates in constant-current mode at 700mA with a CC voltage range of 178-357V. Add up the forward voltages of your LEDs in series and ensure the total falls within that 178-357V window.

Can the HLG-240H-C700AB be mounted outdoors in a covered location?

Yes. The series is rated IP65 or IP67 depending on type, protecting against dust and water, which suits covered outdoor locations such as canopies, soffits, or ventilated enclosures. For heavily exposed installations, check the rating of your type and follow MEAN WELL's IP installation cautions in the user manual.

What is the difference between the HLG-240H-C700AB, C700A, and C700B models?

All three share the same 249.9W / 700mA / 178-357V CC core specs and 244.2 x 68 x 38.8mm case. The C700A has output adjustment only (potentiometer). The C700B has dimming input only (1-10VDC, 10V PWM or resistance). The C700AB combines both adjustment and dimming in one unit, giving you the most control flexibility.
