Mean Well HLG-240H-C700A Power Supply | 249.9W 700mA | Adjustable

Name: Mean Well HLG-240H-C700A Power Supply 249.9W 700mA - Adjustable
Brand: Mean Well
SKU: HLG-240H-C700A
Price: 73.6 USD
Availability: InStock

Overview

HLG-240H-C700A is the model of this series: rated current 700mA, rated power 249.9W, typical efficiency 93.5%. Type A: Io adjustable through built-in potentiometer (IP65).

HLG-240H-C series is a 250W LED AC/DC LED driver featuring the constant current mode and high voltage output. HLG-240H-C operates from 90~305VAC and offers models with different rated current ranging between 700mA and 2100mA. Thanks to the high efficiency up to 94%, with the fanless design, the entire series is able to operate for -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-240H-C is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Features

Constant current mode output
Metal housing with ClassⅠdesign
Built-in active PFC function
IP65 design for indoor or outdoor installations
Function options: output adjustable via potentiometer
Typical lifet ime>62000 hours
7 years warranty

Specifications

HLG-240H-C700ASpecifications from the official datasheet (2026-02-04 edition)

OUTPUT

RATED CURRENT: 700mA
RATED POWER: 249.9W
CONSTANT CURRENT REGION^Note.2: 178 ~ 357V
OPEN CIRCUIT VOLTAGE (max.): 360V
CURRENT ADJ. RANGE: Can be adjusted by internal potentiometer
CURRENT ADJ. RANGE: 350 ~ 700mA
CURRENT RIPPLE: 5.0% max. @rated current
CURRENT TOLERANCE: ±5%
SET UP TIME^Note.4: 1000ms/115VAC, or 500ms/230VAC

INPUT

VOLTAGE RANGE^Note.3: 90 ~ 305VAC 127 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC @full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION: THD< 20% (@ load≧50% /115VAC, 230VAC; @ load≧75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION (THD)” section)
EFFICIENCY (Typ.): 93.5%
AC CURRENT (Typ.): 2.5A / 115VAC 1.3A / 230VAC 1.1A / 277VAC
INRUSH CURRENT(Typ.): COLD START 75A(twidth=700μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER: 2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT: <0.75mA / 277VAC

PROTECTION

SHORT CIRCUIT: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 375 ~ 410V Shut down and latch off o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.: Tcase=-40 ~ +90℃(Refer to "Derating Curve")
MAX. CASE TEMP.: Tcase=+90℃
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750(type”HL”), CSA C22.2 No. 250.13-12; BS EN/EN/AS/NZS 61347-1, BS EN/EN/AS/NZS 61347-2-13, BS EN/EN62384 independent; GB/T19510.1,GB/T19510.213; IP65, EAC TP TC 004 approved
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (@ load≧50%) ; BS EN/EN61000-3-3,GB/T 17743 , GB17625.1, EAC TP TC 020
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN61547, light industry level (surge immunity Line-Earth 4KV, Line-Line 2KV),EAC TP TC 020

OTHERS

MTBF: 2513.7K hrs min. Telcordia SR-332 (Bellcore) ; 228.5K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 244.2*68*38.8mm (L*W*H)
PACKING: 1.3Kg; 12pcs/16.6Kg/0.84CUFT

Certifications & ratings

Type: HL

MODEL ENCODING

A (this model): Io adjustable through built-in potentiometer; IP65
B: 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP67
AB: Io adjustable through built-in potentiometer & 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP65
DX: Built-in Smart timer dimming function by user request; IP67
D2: Built-in Smart timer dimming and programmable function; IP67

Test conditions and notes11

1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
2. Please refer to "DRIVING METHODS OF LED MODULE".
3. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
4. Length of set up time is measured at first cold start. Turning ON/OFF the driver may lead to increase of the set up time.
5. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
6. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED driver can only be used behind a switch without permanently connected to the mains.
7. This series meets the typical life expectancy of >62,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 75℃ or less.
8. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com.
9. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
10. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf
11. For A/AB type need to consider build in using to comply with Type HL application.

Technical drawings

HLG-240H-C700A BLOCK DIAGRAM — BLOCK DIAGRAM

HLG-240H-C700A Illustration (page 5) — Illustration (page 5)

HLG-240H-C700A 250W Constant Current Mode LED Driver — 250W Constant Current Mode LED Driver

HLG-240H-C700A OUTPUT LOAD vs TEMPERATURE(Note.8) — OUTPUT LOAD vs TEMPERATURE(Note.8)

HLG-240H-C700A STATIC CHARACTERISTIC — STATIC CHARACTERISTIC

HLG-240H-C700A TOTAL HARMONIC DISTORTION — TOTAL HARMONIC DISTORTION

HLG-240H-C700A LIFETIME(Kh) — LIFETIME(Kh)

HLG-240H-C700A MECHANICAL SPECIFICATION ※ A-Type — MECHANICAL SPECIFICATION ※ A-Type

Typical applications

LED street lighting
LED fishing lamp
LED harbor lighting
LED building architectural lighting
LED bay lighting
Type “HL” for use in ClassⅠ, Division 2 hazardous (Classified) location.

Downloads

Datasheet1

HLG-240H-C700A datasheetHLG-240H-C-SPEC.PDF · 2026-02-04 edition PDF Download

Certificates4

UL Certificate (HLG-240H-C)(EN) PDF Download

CB Certificate (HLG-240H-C)(EN) PDF Download

EMC Certificate (HLG-240H-C)(EN) PDF Download

ENEC Certificate (HLG-240H-C)(EN) PDF Download

Test reports1

Test Report(HLG-240H-C700)(EN) PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can I use the HLG-240H-C700A to drive a long series string of LEDs for signage?

Yes. The HLG-240H-C700A outputs 700mA constant current with an exceptionally wide CC voltage range of 178-357V, allowing very long series strings of LED modules. This is well suited for large channel-letter signs or long linear LED arrays where many modules are wired in series. The adjustable output lets you reduce current to match your specific LED requirements.

Is the HLG-240H-C700A suitable for driving high-voltage LED street light modules?

Yes, provided the street light module requires approximately 700mA and has a forward voltage within 178-357V. At 249.9W, it can power substantial street or area lighting LED arrays. The series is rated IP65 or IP67 depending on type, and the adjustable output potentiometer lets you fine-tune the drive current during commissioning.

Can the HLG-240H-C700A power a series string of LED downlights in a commercial space?

Yes. The high CC voltage range (178-357V) lets you wire many LED downlight modules in series on a single driver, simplifying wiring in long corridors or large open floor plans. At 700mA and up to 249.9W, the driver maintains consistent brightness across the entire string. The adjustable output accommodates variations in module forward voltage.

Why would I choose the HLG-240H-C700A over a higher-current variant like the C2100A?

The C700A at 700mA and 178-357V suits LED loads with high total forward voltage and lower current draw, such as many LEDs wired in a long series string. The C2100A at 2100mA and 59-119V suits fewer LEDs that each need higher current. Both deliver approximately 250W total. Choose based on your LED module's rated current and the series string voltage.

Is the HLG-240H-C700A safe to install outdoors on a pole or building exterior?

The HLG-240H-C series is rated IP65 or IP67 depending on type, giving dust and water protection for pole-mounted or wall-mounted outdoor installations in sheltered or semi-exposed locations. Check the rating of your specific type and follow MEAN WELL's IP installation cautions in the user manual. It operates over a case temperature (Tcase) range of -40°C to +90°C, with output derating at high ambient temperatures.

Does the output voltage of 360V on the HLG-240H-C700A pose any special safety concerns?

Yes. Its constant current region reaches up to 357V and the open-circuit voltage can be as high as 360V, so the output wiring and connections must be treated as hazardous voltage. Proper insulation, enclosed wiring, and compliance with local electrical codes are required. Over-voltage protection (375-410V) shuts down and latches off the output; re-power to recover.
