Mean Well HLG-240H-C1750B Power Supply 250.25W - Dimmable

Name: Mean Well HLG-240H-C1750B Power Supply 250.25W 1750mA - Dimmable
Brand: Mean Well
SKU: HLG-240H-C1750B
Price: 75.56 USD
Availability: InStock

Overview

HLG-240H-C1750B is the model of this series: rated current 1750mA, rated power 250.25W, typical efficiency 94%. Type B: 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance) (IP67).

HLG-240H-C series is a 250W LED AC/DC LED driver featuring the constant current mode and high voltage output. HLG-240H-C operates from 90~305VAC and offers models with different rated current ranging between 700mA and 2100mA. Thanks to the high efficiency up to 94%, with the fanless design, the entire series is able to operate for -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-240H-C is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Features

Constant current mode output
Metal housing with ClassⅠdesign
Built-in active PFC function
IP67 design for indoor or outdoor installations
Function options: 3 in 1 dimming
Typical lifet ime>62000 hours
7 years warranty

Specifications

HLG-240H-C1750BSpecifications from the official datasheet (2026-02-04 edition)

OUTPUT

RATED CURRENT: 1750mA
RATED POWER: 250.25W
CONSTANT CURRENT REGION^Note.2: 71 ~ 143V
OPEN CIRCUIT VOLTAGE (max.): 146V
CURRENT ADJ. RANGE: 875 ~ 1750mA
CURRENT RIPPLE: 5.0% max. @rated current
CURRENT TOLERANCE: ±5%
SET UP TIME^Note.4: 1000ms/115VAC, or 500ms/230VAC

INPUT

VOLTAGE RANGE^Note.3: 90 ~ 305VAC 127 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC @full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION: THD< 20% (@ load≧50% /115VAC, 230VAC; @ load≧75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION (THD)” section)
EFFICIENCY (Typ.): 94%
AC CURRENT (Typ.): 2.5A / 115VAC 1.3A / 230VAC 1.1A / 277VAC
INRUSH CURRENT(Typ.): COLD START 75A(twidth=700μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER: 2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT: <0.75mA / 277VAC

PROTECTION

SHORT CIRCUIT: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 150 ~ 165V Shut down and latch off o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.: Tcase=-40 ~ +90℃(Refer to "Derating Curve")
MAX. CASE TEMP.: Tcase=+90℃
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750(type”HL”), CSA C22.2 No. 250.13-12; BS EN/EN/AS/NZS 61347-1, BS EN/EN/AS/NZS 61347-2-13, BS EN/EN62384 independent; GB/T19510.1,GB/T19510.213; IP67, EAC TP TC 004 approved
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (@ load≧50%) ; BS EN/EN61000-3-3,GB/T 17743 , GB17625.1, EAC TP TC 020
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN61547, light industry level (surge immunity Line-Earth 4KV, Line-Line 2KV),EAC TP TC 020

OTHERS

MTBF: 2513.7K hrs min. Telcordia SR-332 (Bellcore) ; 228.5K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 244.2*68*38.8mm (L*W*H)
PACKING: 1.3Kg; 12pcs/16.6Kg/0.84CUFT

Certifications & ratings

Type: HL

MODEL ENCODING

A: Io adjustable through built-in potentiometer; IP65
B (this model): 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP67
AB: Io adjustable through built-in potentiometer & 3 in 1 dimming function (1~10Vdc, 10V PWM signal and resistance); IP65
DX: Built-in Smart timer dimming function by user request; IP67
D2: Built-in Smart timer dimming and programmable function; IP67

Test conditions and notes10

1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
2. Please refer to "DRIVING METHODS OF LED MODULE".
3. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
4. Length of set up time is measured at first cold start. Turning ON/OFF the driver may lead to increase of the set up time.
5. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
6. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED driver can only be used behind a switch without permanently connected to the mains.
7. This series meets the typical life expectancy of >62,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 75℃ or less.
8. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com.
9. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
10. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf

Technical drawings

HLG-240H-C1750B BLOCK DIAGRAM — BLOCK DIAGRAM

HLG-240H-C1750B DIMMING OPERATION — DIMMING OPERATION

HLG-240H-C1750B Illustration (page 5) — Illustration (page 5)

HLG-240H-C1750B 250W Constant Current Mode LED Driver — 250W Constant Current Mode LED Driver

HLG-240H-C1750B OUTPUT LOAD vs TEMPERATURE(Note.8) — OUTPUT LOAD vs TEMPERATURE(Note.8)

HLG-240H-C1750B STATIC CHARACTERISTIC — STATIC CHARACTERISTIC

HLG-240H-C1750B TOTAL HARMONIC DISTORTION — TOTAL HARMONIC DISTORTION

HLG-240H-C1750B LIFETIME(Kh) — LIFETIME(Kh)

HLG-240H-C1750B MECHANICAL SPECIFICATION ※ B/D2-Type — MECHANICAL SPECIFICATION ※ B/D2-Type

Typical applications

LED street lighting
LED fishing lamp
LED harbor lighting
LED building architectural lighting
LED bay lighting
Type “HL” for use in ClassⅠ, Division 2 hazardous (Classified) location.

Downloads

Datasheet1

HLG-240H-C1750B datasheetHLG-240H-C-SPEC.PDF · 2026-02-04 edition PDF Download

Certificates4

UL Certificate (HLG-240H-C)(EN) PDF Download

CB Certificate (HLG-240H-C)(EN) PDF Download

EMC Certificate (HLG-240H-C)(EN) PDF Download

ENEC Certificate (HLG-240H-C)(EN) PDF Download

Test reports1

Test Report(HLG-240H-C1750)(EN) PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can I use the HLG-240H-C1750B for a dimmable commercial LED downlight installation?

Yes. The HLG-240H-C1750B delivers 1750mA constant current across a 71-143V range, up to 250.25W. The B suffix provides a 1-10V/PWM dimming input, making it compatible with commercial dimming systems and building management controllers. It can drive high-power downlight modules in series as long as total forward voltage stays within 71-143V.

Is the HLG-240H-C1750B a good fit for dimmable LED flood lights on a building facade?

Yes, provided the flood light's LED array requires approximately 1750mA and has a forward voltage within 71-143V. The series is rated IP65 or IP67 depending on type, and the dimming input allows scene control for architectural lighting effects. For fully exposed installations, check the rating of your type and follow MEAN WELL's IP installation cautions in the user manual.

Can the HLG-240H-C1750B power a high-output LED panel light with dimming?

Yes. At 1750mA and up to 250.25W, it can drive large LED panel lights or troffers. The B variant's 1-10V/PWM dimming input integrates with standard commercial dimming controls. Note this variant does not include an output adjustment potentiometer, so the drive current is fixed at 1750mA before dimming attenuation.

How many LEDs can I run in series with the HLG-240H-C1750B?

The number depends on each LED's forward voltage at 1750mA. The CC voltage range is 71-143V, so you need enough LEDs in series to total at least 71V and no more than 143V. For instance, with LEDs that each drop about 35V at 1750mA, you could run 3 or 4 in series (105-140V). Always verify forward voltages from your LED datasheet.

Can the HLG-240H-C1750B be used inside a sealed outdoor luminaire enclosure?

Yes. The series is rated IP65 or IP67 depending on type, protecting against dust and water. When mounted inside a sealed luminaire, ensure adequate thermal management since the driver generates heat at its 250.25W capacity: the case temperature (Tcase) must stay within -40°C to +90°C, and output derating applies at high ambient temperatures.
