Mean Well

Mean Well HEP-150-54 Power Supply 151.2W 54V 2.8A

fanless designhigh efficiency up to 96%rugged metal case with IP65 design(IP68 option available)withstand 10G vibrationsuitable for harsh environment
SKU HEP-150-54
$99.81 USD
Shipping calculated at checkout.

Select model — 13 in this family

HEP-150-54
Available to order
|

Overview

HEP-150-54 is the 54V output model of this series: rated current 2.8A, rated power 151.2W, typical efficiency 94%. Type Blank: Optional model, with fixed Vo and Io level (IP68).

HEP-150 is a 150W industrial AC/DC power supply featuring the outstanding capability to operate under highly humid, dusty, oily, and high-vibration harsh environment. The entire series is housed with the aluminum case and fully potted with heat-conducted silicone. Thanks to state-of-the-art design, the working efficiency is up to 94%, enabling HEP-150 perfectly work between -55℃ and +70℃ under free air convection.

Features

  • Universal AC input / Full range
  • Built-in active PFC function
  • High efficiency up to 94%
  • Fanless design, cooling by free air convection
  • -55~+70℃ wide operating range
  • Aluminum case and filling with heat-conducted silicone
  • IP65 design, optional IP68 rated model available
  • Meet 6KV surge immunity level
  • Withstand 10G vibration test
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Operating altitude up to 5000 meters (Note.9)
  • 6 years warranty

Specifications

HEP-150-54Specifications from the official datasheet (2025-10-10 edition)

OUTPUT

DC VOLTAGE
54V
RATED CURRENT
2.8A
RATED POWER
151.2W
RIPPLE & NOISE (max.)Note.2
200mVp-p
VOLTAGE ADJ. RANGENote.5
49 ~ 58V
VOLTAGE TOLERANCENote.3
±1.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±0.5%
SETUP, RISE TIMENote.7
1000ms,50ms/115VAC 500ms,50ms/230VAC at full load
HOLD UP TIME (Typ.)
16ms at full load 230VAC /115VAC

INPUT

VOLTAGE RANGENote.4
90~264VAC (277VAC operational) 128~370VDC(390VDC operational)
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
PF>0.98/115VAC, PF>0.95/230VAC, PF>0.92/277VAC at full load
EFFICIENCY (Typ.)
94%
AC CURRENT (Typ.)
1.7A / 115VAC 0.75A / 230VAC 0.7A / 277VAC
INRUSH CURRENT(Typ.)
COLD START 65A at 230VAC
LEAKAGE CURRENT
<0.75mA / 277VAC

PROTECTION

OVERLOAD
105 ~ 125% Protection type : Constant current limiting, recovers automatically after fault condition is removed
SHORT CIRCUIT
Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE
59 ~ 65V
OVER TEMPERATURE
Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.
-55 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY
-60 ~ +80℃, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT
±0.03%/℃ (0 ~ 60℃)
VIBRATION
20 ~ 500Hz, 10G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDSNote.6,9
UL62368-1, IEC62368-1,IP68, EAC TP TC 004 approved ; Design refer to BS EN/EN62368-1
WITHSTAND VOLTAGE
I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, light industry level (surge 6KV), EAC TP TC 020

OTHERS

MTBF
1967.4K hrs min. Telcordia SR-332 (Bellcore) ; 164.2Khrs min. MIL-HDBK-217F (25℃)
DIMENSION
228*68*38.8mm (L*W*H)
PACKING
1.15Kg; 12pcs/14.8Kg/0.8CUFT

MODEL ENCODING

A
Standard model, Vo and Io level can be adjusted through internal potentiometer; IP65
Blank (this model)
Optional model, with fixed Vo and Io level; IP68
Test conditions and notes9
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. Derating may be needed under low input voltages. Please check the static characteristics for more details.
  5. 6. Safety and EMC design refer to BS EN/EN60598-1, CNS15233, GB7000.1, FCC part18.
  6. 7. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time.
  7. 8. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
  8. 9. The water protection level test for the IP68 rating is performed 1000mm below the surface of the water for 1 month.
  9. 10. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

HEP-150-54 Block Diagram
Block Diagram
HEP-150-54 Mechanical Specification
Mechanical Specification

Typical applications

  • Outdoor telecommunication equipment
  • Outdoor electronic signage and billboard
  • Petroleum plant or mine shaft facility

Downloads

FAQ

Can I use the HEP-150-54 for 54V industrial communications or control equipment?

Yes, if the equipment is designed for 54V DC constant-voltage operation. This power supply provides up to 2.8A and 151.2W, so the connected load needs to stay within those limits.

Is the HEP-150-54 suitable for 54V embedded or automation systems in harsh locations?

It can be used for 54V constant-voltage systems that do not exceed 151.2W. The IP68 rating, 10G vibration tolerance, and operating range of -55°C to +70°C make it suitable for demanding industrial environments.

Can this model power 54V DC equipment used in industrial or IT cabinets?

It is appropriate for cabinet-mounted 54V DC equipment when the total draw remains at or below 2.8A. Because it is a constant-voltage supply, the load should explicitly require 54V DC constant-voltage input.

Is the HEP-150-54 rated for outdoor use or harsh weather exposure?

This version is rated IP68, so it is intended for more severe environmental exposure than an IP65 variant. It also operates from -55°C to +70°C, which supports use in very cold or hot conditions.

How does the HEP-150-54 compare with the rest of the HEP-150 family?

Across the HEP-150 line, HEP-150-12 and HEP-150-12A are 150W at 12V and 12.5A, HEP-150-15 and HEP-150-15A are 150W at 15V and 10A, HEP-150-24 and HEP-150-24A are 151.2W at 24V and 6.3A, HEP-150-36 and HEP-150-36A are 151.2W at 36V and 4.2A, HEP-150-48 and HEP-150-48A are 153.6W at 48V and 3.2A, and HEP-150-54 and HEP-150-54A are 151.2W at 54V and 2.8A. This SKU has the same 54V, 2.8A, and 151.2W electrical rating as HEP-150-54A.
