Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well HDP-190 Dual Output with PFC Function Switching Power Supply
$59.38 USD
Unit price /
Unavailable
Description
Description
Features
| Universal AC input / Full range |
| Built-in active PFC function |
| High efficiency up to 86% |
| Protection: Short circuit / Over current / Over voltage / Over Temperature |
| Cooling by free air convection |
| 1U low profile 36mm |
| Conformal coated |
| ZVS technology to reduce power dissipation |
| LED indicator for power on |
| 3 years warranty |
General Specification
| Line regulation (max.) | ± 0.5% |
| Load regulation (max.) | ± 2.0% |
| Overload protection Range | V1+V2: 105 ~ 150% max. output power ; or V2: 125 ~ 170% rated current |
| Overload protection Type | Hiccup mode, recovers automatically after fault condition is removed |
| Over-voltage protection | Shut down o/p voltage, re-power on to recover |
| Withstand voltage | I/P-O/P:3KVAC | I/P-FG:1.5KVAC | O/P-FG:0.5KVAC |
| Isolation resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH |
| Working temperature | -30 ~ +70 ℃ (Refer to "Derating Curve") |
| Safety standards | UL 62368-1, IEC/BS EN/EN 62368-1, EAC TP TC 004 approved; design refer to GB4943.1 |
| Dimension (LxWxH) (mm) | 215*115*36mm (L*W*H) |
| Packing | 0.95Kg; 15pcs/15.3Kg/0.7CUFT |
Specifications
Specifications
-
BrandMean Well
-
SeriesMean Well HDP Series
-
Power Rating181.4 Watt
-
Output Voltage3.8 Volt
-
Rated Current33 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CCC,UL
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.42 in
-
Weight2.09 lb
