Mean Well GSM12U15-P1J Power Supply 12W 15V 800mA

SKU GSM12U15-P1J
$20.27 USD
Shipping calculated at checkout.

Select model — 10 in this family

GSM12U15-P1J
In stock
|

Overview

GSM12U15-P1J is the 15V output model of this series: rated current 0.8A, typical efficiency 84%.

GSM12U is a highly reliable, 12W wall-mounted style single-output green medical adaptor series, which is compact and convient for carry. This product is equipped with the standard 2-pin U.S. plug. GSM12U is a class Ⅱ power unit (no FG), accepting the input range from 80VAC to 264VAC that it can satisfy the demands for various types of medical electrical devices. The circuitry design meets the international medical standards (2*MOPP), having an ultra low leakage current (<100μA), fitting the medical devices in direct electrical contact with the patients. With the working effiiciency up to 87% and the extremely low no-load power consumption below 0.075W (<0.1W for 18V/48V), GSM12U is compliant with the latest USA energy regulation EISA 2007/DoE(Level Ⅵ). The supreme feature allows the adaptor to save the energy when it is under either the operating mode or the standby mode. The entire series is approved for international safety regulations; moreover, it adopts the 94V-0 flame retadant plastic case that it can effeclively prevent users from electric hazarad.

Features

  • Universal AC input / Full range
  • Medical safety approved (2 x MOPP) according to ANSI/AAMI ES60601-1/ES60601-1-11
  • Extremely low leakage current
  • No load power consumption< 0.075W(<0.1W for 18V/48V)
  • Energy efficiency Level Ⅵ
  • -20~+70℃ wide range working temperature
  • Class Ⅱ power (no earth pin)
  • Protections: Short circuit / Overload / Over voltage
  • Fully enclosed plastic case
  • Various DC plug quick adaptor accessory available (Plug kit sold sperately, please refer to : https://www.meanwell.com/upload/pdf/DC_plug.pdf)
  • 3 years warranty

Specifications

GSM12U15-P1JSpecifications from the official datasheet (2022-04-15 edition)

OUTPUT

SAFETY MODEL NO.
GSM12U15
DC VOLTAGENote.2
15V
RATED CURRENT
0.8A
CURRENT RANGE
0 ~ 0.8A
RATED POWER (max.)
12W
RIPPLE & NOISE (max.)Note.3
80mVp-p
VOLTAGE TOLERANCENote.4
±3.0%
LINE REGULATIONNote.5
±1.0%
LOAD REGULATIONNote.6
±3.0%
SETUP, RISE, HOLD UP TIME
500ms, 30ms, 16ms/230VAC 500ms, 30ms, 16ms/115VAC at full load

INPUT

VOLTAGE RANGENote.7
80 ~ 264VAC 113 ~ 370VDC
FREQUENCY RANGE
47 ~ 63Hz
EFFICIENCY (Typ.)
84%
AC CURRENT
0.4A / 115VAC 0.2A / 230VAC
INRUSH CURRENT (max.)
Cold start 30A / 115VAC 60A / 230VAC
LEAKAGE CURRENT(max.)
Touch current < 100μA/264VAC

PROTECTION

OVERLOAD
110 ~ 200% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
110 ~ 140% rated output voltage Protection type : Clamp by zener diode, output short

ENVIRONMENT

WORKING TEMP.
-20 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY
0 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY
-20 ~ +85℃, 0 ~ 95% RH non-condensing
TEMP. COEFFICIENT
±0.03% / ℃ (0 ~ 40℃)
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC (Note. 8)

SAFETY STANDARDS
ANSI/ AAMI ES60601-1/ES60601-1-11(3.1 version), CAN/CSA-C22 NO. 60601-1 3rd edition, EAC TP TC 004 approved GSM12U05-USB without ANSI/ AAMII ES60601-1-11
ISOLATION LEVEL
Pimary - Secondary: 2 x MOPP
WITHSTAND VOLTAGE
I/P-O/P:5656VDC
ISOLATION RESISTANCE
I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
ParameterStandardTest Level
Conducted emissionFCC PART 15 / CISPR22Class B
Radiated emissionFCC PART 15 / CISPR22Class B

OTHERS

LIFE
3 years : 100% load 40℃, 12hours / day
MTBF
400Khrs min. MIL-HDBK-217F(25℃)
DIMENSION
62.2*27.4*45.5mm (L*W*H)
PACKING
109g, 110pcs / 13kg / CARTON for cable connection ; 73g, 150pcs / 12kg / CARTON for USB connection

CONNECTOR

PLUG
See page 4~5 ; other type available by customer requested
CABLE
See page 4~5 ; other type available by customer requested

Certifications & ratings

IP rating
IP22
Test conditions and notes8
  1. 1.All parameters are specified at 115VAC input, rated load, 25℃ 70% RH ambient.
  2. 2.DC voltage: The output voltage set at point measure by plug terminal & 50% load.
  3. 3.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1μf & 47μf capacitor.
  4. 4.Tolerance: includes set up tolerance, line regulation, load regulation.
  5. 5.Line regulation is measured from low line to high line at rated load.
  6. 6.Load regulation is measured from 10% to 100% rated load.
  7. 7.Derating may be needed under low input voltage. Please check the derating curve for more details.
  8. 8.The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com)

Technical drawings

GSM12U15-P1J Derating Curve
Derating Curve
GSM12U15-P1J Mechanical Specification
Mechanical Specification
GSM12U15-P1J DC output plug
DC output plug
GSM12U15-P1J Illustration (page 5)
Illustration (page 5)

Typical applications

  • Blood glucose meter
  • Blood pressure meter
  • Nebulizer
  • Inhaler
  • Portable medical device
  • Sleep apnea devices

Downloads

FAQ

Can I use the GSM12U15-P1J to power a small 15V industrial controller?

Yes, this model is a constant-voltage 15V power supply rated for 12W and 0.8A. It fits low-power industrial control devices that specifically require a regulated 15V DC input and stay within that 0.8A output limit.

Is this power supply suitable for a 15V embedded system or electronics prototype?

It can be a fit for embedded or bench-built equipment that needs 15V constant voltage and no more than 12W total load. The wide 80-264VAC input also makes it practical where AC input conditions may vary across sites or regions.

Can this 15V adapter be used for low-power automation sensors or interface modules?

It is appropriate for 15V automation accessories or interface modules as long as the combined load does not exceed 0.8A at 15V. Because it is a constant-voltage unit, it is intended for equipment designed to accept a fixed 15V DC supply.

Would this work for a compact 15V lab or test fixture?

Yes, it suits compact test fixtures or light-duty electronics that call for 15V DC and stay within the 12W rating. Its small 62.2 × 27.4 × 45.5 mm (L × W × H) housing also helps where space is limited.

Is the GSM12U15-P1J suitable for outdoor use or harsh ambient conditions?

The unit is rated IP22, so it should be treated as a supply for dry, protected environments unless the final equipment provides its own enclosure. Its stated operating temperature range is -20°C to +70°C, with load derating at higher ambient temperatures.
