Mean Well

Mean Well GC160A48-R7B Portable Chargers 160.5W 54.4V 2.95A - Green Adaptor

class I powerno load power consumption < 1.0W2 stage charging
SKU GC160A48-R7B
$53.99 USD
Shipping calculated at checkout.
In stock
|

Overview

GC160A48-R7B is the model of this series: rated power 160.5W, typical efficiency 94%.

Features

  • Charger for lead-acid batteries (flooded,Gel and AGM) and Li-ion batteries (lithium iron and lithium manganese) (Note.1)
  • 2 stage charging characteristic
  • Universal AC input / Full range
  • Built-in active PFC function, PF>0.94
  • No load power consumption<1W
  • 3 pole AC inlet IEC320-C14
  • Class I power ( with earth pin)
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Cooling by free air convection
  • Fully enclosed plastic case
  • 2 color LED indicator for charging status
  • Approvals: UL / TUV / EAC / CB / FCC / CE / UKCA
  • 2 years warranty

Specifications

GC160A48-R7BSpecifications from the official datasheet (2024-10-30 edition)

OUTPUT

SAFETY MODEL NO.
GC160A48
DC VOLTAGE (Typ.)
54.4V
RECOMMENDED BATTERY CAPACITYNote.3
15 ~ 45Ah
CONTINUOS OUTPUT CURRENT (Typ.)
2.95A
RATED POWER
160.5W
LED INDICATOR
Charging(CC) : RED Floating charging(CV) : GREEN

INPUT

VOLTAGE RANGENote.4
85 ~ 264VAC 120 ~ 370VDC
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
PF>0.94 / 230VAC PF>0.98 / 115VAC at full load
EFFICIENCY (Typ.)
94%
AC CURRENT
1.85A / 115VAC 1A / 230VAC
INRUSH CURRENT (max.)
120A / 230VAC
LEAKAGE CURRENT(max.)
0.75mA / 240VAC

PROTECTION

OVERLOADNote.5
90 ~ 110% rated output power Protection type : Constant current limiting recovers automatically after fault condition is removed
SHORT CIRCUIT
Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
105 ~ 135% rated output voltage Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE
90℃±10℃ (RTH2) detect on inside ambient temperature Protection type : Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.
-30 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20% ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-40 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03% / ℃ (0~50℃)
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDSNote.6
UL1012 (for GC160Axx-AD1 only), TUV BS EN/EN62368-1, EAC TP TC 004 approved
WITHSTAND VOLTAGE
I/P-O/P: 3KVAC
ISOLATION RESISTANCE
I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to BS EN/EN55032 class B, BS EN/EN61000-3-2,3, FCC PART 15 / CISPR22 class B, CAN ICES-3(B)-NMB-(B), EAC TP TC 020
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, light industry level, EAC TP TC 020

OTHERS

MTBF
2197.9K hrs min. Telcordia SR-332 (Bellcore) ; 274.1K hrs min. MIL-HDBK-217F (25℃)
DIMENSION
175*72*35mm (L*W*H)
PACKING
0.7Kg; 20pcs/15Kg/0.95CUFT(GC160Axx-R7B) 0.77Kg; 20pcs/16.4Kg/1.15CUFT(GC160Axx-AD1)

CONNECTOR

PLUG
See page 2 ; Other type available by customer requested
CABLE
See page 2 ; Other type available by customer requested
Test conditions and notes7
  1. 1. Modification for charger specification may be required for different battery specification. Please contact battery vendor and MEAN WELL for details.
  2. 2. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  3. 3. This is MeanWell's suggested range, please consult your battery manufacturer for their suggestions about maximum charging current limitation.
  4. 4. Derating may be needed under low input voltage. Please check the derating curve for more details.
  5. 5. Constant current operation region is within 50~100% rated output voltage.
  6. 6. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
  7. 7. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

GC160A48-R7B Mechanical Specification
Mechanical Specification
GC160A48-R7B Plug Assignment
Plug Assignment
GC160A48-R7B Derating Curve
Derating Curve

Downloads

FAQ

What is the main use case for the Mean Well GC160A48-R7B?

The GC160A48-R7B is an AC/DC battery charger designed for 54.4V output charging of lead-acid and Li-ion batteries. It delivers up to 160.5W and 2.95A, making it suitable for business use where a compact external charger is needed for compatible 48V-class battery systems of 15 to 45Ah.

What output rating does this charger provide?

This model provides a 54.4V DC output with a rated current of 2.95A. Its rated power is 160.5W, the highest in the GC160 series.

What input range does the GC160A48-R7B support?

The unit supports a universal input range of 85 to 264VAC, and it also accepts 120 to 370VDC. That wide range makes it practical for buyers who need one charger platform for varied mains environments.

Is this model suitable for demanding industrial or field environments?

It is built for a broad operating temperature range of -30°C to +70°C, subject to the manufacturer's derating guidance. The fully enclosed plastic case, free-air convection cooling, and built-in protection features support use in tougher commercial environments.

What protection and efficiency features does this charger include?

The GC160A48-R7B includes protection against short circuit, overload, over voltage, and over temperature. It also features active PFC, no-load power consumption below 1W, and efficiency up to 94%, which helps reduce wasted energy in continuous-use settings.

How does the R7B version differ from other charger variants?

This version uses a 4-pin power DIN output connector (KYCON KPP-4S or equivalent), while the AD1 version uses an Anderson connector. UL1012 approval applies to the AD1 version only, so confirm both the connector and the approvals your equipment requires.

What compliance and warranty details are provided for this model?

The R7B version is listed with TUV BS EN/EN62368-1 safety approval and EAC, with EMC compliance including EN55032 Class B and FCC Part 15 Class B. Mean Well also specifies a 2-year warranty for this charger.
