Mean Well

Mean Well EPP-100-27 Power Supply 75W 27V 2.8A

4" x 2"high efficiency up to 92%economical PFCno load power consumption<0.5W
SKU EPP-100-27
$45.81 USD
Shipping calculated at checkout.
In stock
|

Overview

EPP-100-27 is the 27V output model of this series: typical efficiency 92.5%.

Features

  • 4"x2" Compact size
  • Universal AC input / Full range
  • Built-in active PFC function
  • High efficiency up to 92.5%
  • Protections: Short circuit / Overload / Over voltage/Over temperature
  • 75W free air convection, 100W with 20CFM forced air
  • LED indicator for power on
  • No load power consumption<0.5W
  • Built-in 12V/0.3A auxiliary output
  • 3 years warranty

Specifications

EPP-100-27Specifications from the official datasheet (2026-03-31 edition)

OUTPUT

DC VOLTAGE
27V
RATED CURRENT (convection)
2.8A
RATED CURRENT (20CFM FAN)
3.71A
CURRENT RANGE (convection)
0 ~ 2.8A
CURRENT RANGE (20CFM FAN)
0 ~ 3.71A
RATED POWER (convection)
75.6W
RATED POWER (20CFM FAN)
100.17W
RIPPLE & NOISE (max.)Note.2
240mVp-p
VOLTAGE ADJ. RANGE
26.46 ~ 28.35V
VOLTAGE TOLERANCENote.3
±1.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.0%
SETUP, RISE TIME
1000ms, 30ms/230VAC 2000ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.)
16ms/230VAC 16ms/115VAC at full load

INPUT

VOLTAGE RANGENote.5
90 ~ 264VAC 127 ~ 370VDC
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
PF>0.95/230VAC PF>0.98/115VAC at full load
EFFICIENCY (Typ.)
92.5%
AC CURRENT (Typ.)
1.4A/115VAC 0.7A/230VAC
INRUSH CURRENT (Typ.)
COLD START 70A/230VAC
LEAKAGE CURRENT
<2mA/240VAC

PROTECTION

OVER LOAD
105 ~ 145% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
30.2 ~ 34.05V Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE
110℃±10℃ (RTH2),110℃±5℃ (TSW2) Protection type : Shut down o/p voltage, re-power on to recover

FUNCTION

AUXILIARY POWER(AUX)
12V@0.3A for driving a fan, tolerance ±10% at main output 100% load

ENVIRONMENT

WORKING TEMP.
-30 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-40 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03%/℃ (0 ~ 45℃)
OPERATING ALTITUDENote.6
2000 meters
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC (Note 4)

SAFETY STANDARDS
UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved
WITHSTAND VOLTAGE
I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC/ 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, heavy industry level, EAC TP TC 020

OTHERS

MTBF
2401.7K hrs min. Telcordia SR-332 (Bellcore) ; 249.6K hrs min. MIL-HDBK-217F (25℃)
DIMENSION
101.6*50.8*29mm (L*W*H)
PACKING
0.2Kg; 72pcs/15.4Kg/0.82CUFT
Test conditions and notes6
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
  5. 5. Derating may be needed under low input voltages. Please check the derating curve for more details.
  6. 6. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

EPP-100-27 Mechanical Specification
Mechanical Specification
EPP-100-27 Block Diagram
Block Diagram
EPP-100-27 Output Derating
Output Derating

Downloads

FAQ

Can I use the EPP-100-27 for 27V industrial control or test equipment?

Yes, this model is a constant-voltage 27V supply rated for 2.8A and 75.6W with convection cooling, or 3.71A and 100.17W with a 20CFM fan. It fits industrial or embedded equipment that specifically requires 27V DC and stays within those output limits.

Is the EPP-100-27 suitable for a 27V automation panel subsystem?

It can be used for a 27V automation subsystem when the connected load needs constant-voltage 27V power and draws no more than 2.8A (3.71A with a 20CFM fan). The wide 90-264VAC input also helps when the equipment is deployed across facilities with different AC supply standards.

Can this 27V power supply run embedded electronics that need stable DC output?

Yes, the EPP-100-27 is designed for constant-voltage output at 27V with up to 75.6W available with convection cooling (100.17W with a 20CFM fan). That makes it appropriate for embedded electronics, instruments, or control assemblies that are designed for 27V DC and need 2.8A or less (3.71A with the fan).

Is the EPP-100-27 meant for outdoor or exposed environments?

This unit has an operating temperature range of -30°C to +70°C, with output derating at higher temperatures (see the derating curve), but no IP rating is listed in the specs. That points to use inside protected equipment or an enclosure rather than direct outdoor or washdown exposure.
