Mean Well ELN-30-24D Single Output Switching Power Supply 30W 24V CC
$27.50 USD
Unit price /
Unavailable
Description
Description
Features
| Universal AC input / Full range |
| Fully isolated plastic case with IP64 level |
| Built-in constant current limiting circuit with adjustable OCP level |
| Protections: Short circuit / Overload / Over voltage |
| Optional dimming function: 1.1~10VDC (D type) or PWM (P type) controlled |
| UL1310 Class 2 power unit |
| Cooling by free air convection |
| 100% full load burn-in test |
| Suitable for LED lighting and moving sign applications |
| Low cost |
| 2 years warranty |
General Specification
| Line regulation (max.) | ± 1.0% |
| Load regulation (max.) | ± 2.0% |
| Overload protection Range | 95 ~ 110% |
| Overload protection Type | Constant current limiting, recovers automatically after fault condition is removed |
| Over-voltage protection | Shut down o/p voltage, re-power on to recover |
| Withstand voltage | I/P-O/P:3KVAC |
| Isolation resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH |
| Working temperature | -20 ~ +60 ℃ (Refer to ""Derating Curve"") |
| Safety standards | UL1310 Class 2, CAN/CSA C22.2 No. 223-M91(except for 48V), IP64 approved, design refer to TUV EN60950-1, EN61347-2-13 |
| Dimension (LxWxH) (mm) | 145*47*30mm (L*W*H) |
| Packing | 0.26Kg; 60pcs/16.6Kg/1.25CUFT |
Specifications
Specifications
-
BrandMean Well
-
SeriesMean Well ELN Series
-
Power Rating30 Watt
-
Output Voltage24 Volt
-
Rated Current0.00 Ampere
-
Input Voltage90V~264V
-
Standards MetCE,cUL,UL
-
Operation ModeConstant Current
-
Operating Temperature60°C~-20°C
-
Warranty2 Year
-
Length5.71 in
-
Width1.85 in
-
Height1.18 in
-
Weight0.57 lb
