Mean Well ELG-300-12A Power Supply - Buy Now at Best Prices in US

Name: Mean Well ELG-300-12A Power Supply 264W 12V - Adjustable 22A
Brand: Mean Well
SKU: ELG-300-12A
Price: 86.78 USD
Availability: InStock

Overview

ELG-300-12A is the 12V output model of this series: typical efficiency 91%.

ELG-300 series is a 300W LED driver featuring with constant current and Constant voltage mode design. ELG-300 operates from 100~305VAC and offers CV mode or CC mode applications. Thanks to the high efficiency up to 94%, with the fanless design, the ambient temperature can be operated for -40℃~+85℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world ,as to provide the optimal design flexibility for LED lighting system.

Features

Constant Voltage + Constant current mode output
Protection Functions: OCP,SCP,OVP,OTP
IP67 rating for indoor or outdoor installations
Output adjustable via potentiometer
Typical lifetiem>50000 hours
5 years warranty

Specifications

ELG-300-12ASpecifications from the official datasheet (2026-02-04 edition)

OUTPUT

DC VOLTAGE: 12V
CONSTANT CURRENT REGION^Note.2: 10~ 12V
RATED CURRENT 200VAC ~ 305VAC: 22A
RATED CURRENT 100VAC ~ 180VAC: 18.7A
RATED POWER 200VAC ~ 305VAC: 264W
RATED POWER 100VAC ~ 180VAC: 224.4W
RIPPLE & NOISE (max.)^Note.3: 150mVp-p
VOLTAGE ADJ. RANGE: 11.2 ~12.8V
CURRENT ADJ. RANGE: 11 ~ 22A
VOLTAGE TOLERANCE^Note.4: ±3.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±2.0%
SETUP, RISE TIME^Note.6: 500ms, 100ms/230VAC, 500ms, 100ms/115VAC
HOLD UP TIME (Typ.): 10ms/ 230VAC 10ms/ 115VAC

INPUT

VOLTAGE RANGE^Note.5: 100 ~ 305VAC 142 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR: PF≧0.95/115VAC, PF≧0.93/230VAC, PF≧0.90/277VAC@full load
TOTAL HARMONIC DISTORTION: THD< 10%(@load≧50%/115VC,230VAC; @load≧75%/277VAC)
EFFICIENCY (Typ.): 91%
AC CURRENT: 3A / 115VAC 1.6A / 230VAC 1.3A/277VAC
INRUSH CURRENT(Typ.): COLD START 45A(twidth=1200μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER: 2 units (circuit breaker of type B) / 4 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT: <0.75mA / 277VAC

PROTECTION

OVER CURRENT: 95 ~ 108% Constant current limiting, recovers automatically after fault condition is removed
SHORT CIRCUIT: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 13.5 ~ 17V Shut down output voltage, re-power on to recover
OVER TEMPERATURE: Shut down output voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.: Tcase=-40 ~ +85℃ (Please refer to " OUTPUT LOAD vs TEMPERATURE" section)
MAX. CASE TEMP.: Tcase=+85℃
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 60℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750(type"HL")(Except for 12V), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384; EAC TP TC 004; GB/T19510.1,GB/T19510.213; KC61347-1,KC61347-2-13; IS15885(Part2/Sec13), IP67 approved; Designed refer to AS/NZS 61347 & AS/NZS 60598
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (@load≧50%) ; BS EN/EN61000-3-3;GB/T 17743,GB17625.1;KN15
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547, light industry level (surge immunity Line-Earth 6KV, Line-Line 4KV),KN61547

OTHERS

MTBF: 1827.7K hrs min. Telcordia SR-332 (Bellcore) ; 196.5Khrs min. MIL-HDBK-217F (25℃)
DIMENSION: 246*77*39.5mm (L*W*H)
PACKING: 1.45 Kg; 9pcs /13.5Kg / 0.76CUFT

Certifications & ratings

Type: A

Test conditions and notes14

1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
2. Please refer to "DRIVING METHODS OF LED MODULE".
3. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
4. Tolerance : includes set up tolerance, line regulation and load regulation.
5. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
6. Length of set up time is measured at first cold start. Turning ON/OFF the driver may lead to increase of the set up time.
7. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
8. This series meets the typical life expectancy >50,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is 70℃ or less.
9. RCM is on a voluntary basis. Non IC classification Independent LED control gear is not suitable for residential installations.
10. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com
11.The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
12. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED driver can only be used behind a switch without permanently connected to the mains.
13. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf
14. This series need to consider build in using to comply with Type HL application.

Technical drawings

ELG-300-12A Block Diagram — Block Diagram

ELG-300-12A OUTPUT LOAD vs TEMPERATURE — OUTPUT LOAD vs TEMPERATURE

ELG-300-12A STATIC CHARACTERISTIC — STATIC CHARACTERISTIC

ELG-300-12A TOTAL HARMONIC DISTORTION — TOTAL HARMONIC DISTORTION

ELG-300-12A MECHANICAL SPECIFICATION — MECHANICAL SPECIFICATION

ELG-300-12A Recommend Mounting Direction — Recommend Mounting Direction

Typical applications

LED bay lighting
LED stage lighting
LED flood lighting
LED strip lighting
DMX control system

Downloads

Certificates9

Mean Well ELGC-300 CCC Certificate PDF Download

Mean Well ELGC-300 ENEC Certificate PDF Download

Mean Well ELGC-300 CB Certificate PDF Download

Mean Well ELGC-300 EMC Certificate PDF Download

Mean Well ELGC-300 CE Certificate PDF Download

Mean Well ELGC-300 KC Certificate PDF Download

Mean Well ELGC-300 UK Certificate PDF Download

Mean Well IDLC Series UL Certificate PDF Download

Mean Well IDLC Series EAC Certificate PDF Download

Test reports1

Mean Well ELG-300-12A Test Report PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can the ELG-300-12A power 12V LED strip lighting in large outdoor landscape or pathway installations?

Yes. The ELG-300-12A is IP67 approved, providing waterproof protection suitable for outdoor landscape and pathway lighting. Its working case temperature (Tcase) range of -40°C to +85°C accommodates the thermal swings of year-round outdoor installations; output derating applies at higher temperatures per the output load vs temperature curve.

How many meters of 12V LED strip can the ELG-300-12A support?

The ELG-300-12A delivers 264W at 12V on 200–305VAC input (224.4W on 100–180VAC). At 264W, a 14.4 W/m strip supports approximately 18.3 meters (264 ÷ 14.4) and a 10 W/m strip approximately 26 meters; at 224.4W, approximately 15.6 and 22 meters. Always verify your strip's rated power per meter and leave some headroom.

Is the ELG-300-12A suitable for powering 12V LED lighting in large illuminated outdoor sign cabinets?

Yes. With 264W at 12V and a 22A rated output (on 200–305VAC input; 224.4W / 18.7A on 100–180VAC), this driver can handle substantial 12V LED module or strip loads inside large sign boxes. The IP67-approved housing allows installation in outdoor sign enclosures exposed to rain and humidity.

Can I use the ELG-300-12A for 12V LED lighting in refrigerated display or cold-storage environments?

Yes. The working case temperature range starts at -40°C, making the ELG-300-12A suitable for cold-storage, walk-in cooler, or freezer display lighting applications. The IP67-approved enclosure protects against dust and water; note that the rated working humidity is 20–95% RH non-condensing.

What does the 'A' suffix mean on the ELG-300-12A, and what does it allow you to adjust?

The A type has adjustable output voltage and current. The voltage can be set within 11.2–12.8V and the current within 11–22A, which is useful for compensating voltage drop in long cable runs or fine-matching the driver to specific LED load requirements.

Is the ELG-300-12A well suited for 12V LED theatrical or stage lighting rigs that operate in harsh environments?

Yes. The wide input range of 100–305VAC accommodates international voltages, the IP67 rating provides protection from dust and water, and the -40°C to +85°C working case temperature range covers demanding stage or event environments. The 22A output (18.7A on 100–180VAC input) supports high-current 12V LED wash or flood fixtures.
