Name: Mean Well DDR-60L-15 DC-DC Converter - 60W - 18~75V in 15V out 4A
Brand: Mean Well
SKU: DDR-60L-15
Price: 36.15 USD
Availability: InStock

Overview

DDR-60L-15 is the 15V output model of this series: rated current 4A, rated power 60W, typical efficiency 92%.

DDR-60 series is a 60W DIN Rail type DC-DC converter with main features including DIN rail-type easy installation, ultra slim width (52.5mm), 4:1 ultra wide input voltage, -40~+85℃ wide operating temperature, 4KVdc I/O isolation, adjustable output voltage ( 10%) and full protective functions...etc. This series has two input options: 9~36V /18~75V and various output options: 5V / 12V / 15V / 24V and can be used for industrial control, security control, communication system and other fields. Suitable applications are DC buck/boost regulator, increasing system insulation level and voltage drop compensation along cable...etc.

Features

Width only 52.5mm (3SU)
4:1 ultra wide input range
-40~+85℃ wide working temperature
No minimum load required
DC output adjustable (±10%)
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection
4KVdc I/O isolation(Reinforced isolation)
3 years warranty

Specifications

DDR-60L-15Specifications from the official datasheet (2026-03-31 edition)

OUTPUT

DC VOLTAGE: 15V
RATED CURRENT: 4A
CURRENT RANGE: 0 ~ 4A
RATED POWER: 60W
RIPPLE & NOISE (max.)^Note.2: 75mVp-p
VOLTAGE ADJ. RANGE: 13.5 ~ 16.5V
VOLTAGE TOLERANCE^Note.3: ±2.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±0.5%
SETUP, RISE TIME: 120ms, 85ms at full load
HOLD UP TIME (Typ.): L-type: 10ms@48Vdc input
EXTERNAL CAPACITANCE LOAD (Max.): 3300μF

INPUT

VOLTAGE RANGE^Note.4: 18 ~ 75Vdc
EFFICIENCY (Typ.): 92%
DC CURRENT (Typ.): 1.5A /48Vdc
INRUSH CURRENT (Typ.): 20A /48Vdc

PROTECTION

OVERLOAD: 105 ~ 135% rated output power Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 17.25 ~ 20.25V Protection type : Shut down o/p voltage, re-power on to recover
REVERSE POLARITY: By internal MOSFET, no damage, recovers automatically after fault condition removed
UNDER VOLTAGE LOCKOUT: 24Vin (G-type):Power ON≥9V , OFF≤8.5V 48Vin (L-type):Power ON≥18V , OFF≤17V

ENVIRONMENT

WORKING TEMP.: -40 ~ +85℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 5 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +85℃, 5 ~ 95% RH non-condensing
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~60℃)
VIBRATION: Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6
OPERATING ALTITUDE: 5000 meters

SAFETY & EMC (Note 5)

SAFETY STANDARDS: IEC 62368-1, UL 62368-1, AS/NZS 62368-1, EAC TP TC 004 approved
WITHSTAND VOLTAGE: I/P-O/P:4KVdc
ISOLATION RESISTANCE: I/P-O/P>100M Ohms / 500Vdc / 25℃/ 70% RH
EMC EMISSION: Parameter Standard Test Level

Conducted BS EN/EN55032 Class A
Radiated BS EN/EN55032 Class A for 1m I/O cable , Class B for 30cm I/O cable
Voltage Flicker BS EN/EN61000-3-3 -----; BS EN/EN55035 , BS EN/EN61000-6-2(BS EN/EN50082-2)
EMC IMMUNITY: Parameter Standard Test Level

ESD BS EN/EN61000-4-2 Level 3, 8KV air; Level 3, 6KV contact; criteria A
Radiated BS EN/EN61000-4-3 Level 3, 10V/m; criteria A
EFT / Burst BS EN/EN61000-4-4 Level 3, 2KV; criteria A
Surge BS EN/EN61000-4-5 Level 3, 1KV/Line-Line; criteria A
Conducted BS EN/EN61000-4-6 Level 3, 10V; criteria A
Magnetic Field BS EN/EN61000-4-8 Level 4, 30A/m; criteria A

Parameter	Standard	Test Level
Conducted	BS EN/EN55032	Class A
Radiated	BS EN/EN55032	Class A for 1m I/O cable , Class B for 30cm I/O cable
Voltage Flicker	BS EN/EN61000-3-3	-----; BS EN/EN55035 , BS EN/EN61000-6-2(BS EN/EN50082-2)

Parameter	Standard	Test Level
ESD	BS EN/EN61000-4-2	Level 3, 8KV air; Level 3, 6KV contact; criteria A
Radiated	BS EN/EN61000-4-3	Level 3, 10V/m; criteria A
EFT / Burst	BS EN/EN61000-4-4	Level 3, 2KV; criteria A
Surge	BS EN/EN61000-4-5	Level 3, 1KV/Line-Line; criteria A
Conducted	BS EN/EN61000-4-6	Level 3, 10V; criteria A
Magnetic Field	BS EN/EN61000-4-8	Level 4, 30A/m; criteria A

OTHERS

MTBF: 3261.6K hrs min. Telcordia SR-332 (Bellcore) ; 611.1K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 52.5*90*54.5mm (W*H*D)
PACKING: 216g; 60pcs/14Kg/0.97CUFT

Test conditions and notes6

1. All parameters NOT specially mentioned are measured at normal input (G:24Vdc, L:48Vdc), rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltage. Please check the derating curve for more details.
5. The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
6. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

DDR-60L-15 Block Diagram — Block Diagram

DDR-60L-15 Derating Curve — Derating Curve

DDR-60L-15 Output derating VS input voltage — Output derating VS input voltage

DDR-60L-15 Mechanical Specification — Mechanical Specification

Typical applications

Downloads

Certificates4

CE Certificate(DDR-60)(EN) PDF Download

UL Certificate(DDR-60)(EN) PDF Download

EMC Certificate(DDR-60)(EN) PDF Download

EAC Certificate(EN) PDF Download

Catalogues2

Mean Well DC-DC Catalog PDF Download

Mean Well Catalog (Industrial) PDF Download

FAQ

Can I use the DDR-60L-15 to power 15V industrial sensors from a 48V DC distribution bus?

Yes. The DDR-60L-15 accepts 18-75V DC input, which covers standard 48V buses. It outputs 15V at up to 4A (60W), making it well suited for powering arrays of 15V industrial sensors, transducers, or measurement instruments mounted on DIN rail in control panels.

Is the DDR-60L-15 suitable for providing isolated 15V power to analog signal-conditioning boards in a process control system?

Yes. Its 4KVdc input-to-output isolation separates the 48V or 24V source bus from the 15V analog circuitry, and ripple and noise are 75mVp-p max. At 60W and 4A it has headroom for multiple signal-conditioning modules that typically draw a few hundred milliamps each.

Can the DDR-60L-15 convert a 24V battery bank to 15V for laboratory bench instruments?

Yes, provided the battery voltage stays within the 18-75V input range. A 24V lead-acid bank typically sits between 20V and 29V, which is well within spec. The DDR-60L-15 delivers a stable 15V at up to 4A, suitable for test instruments, data loggers, or bench-top devices in mobile labs.

Will the DDR-60L-15 function in a high-temperature rooftop telecom enclosure during summer?

Yes, within limits. Its operating range is -40°C to +85°C ambient, but output must be derated at higher temperatures according to the datasheet's derating curve. Check your load against that curve and ensure the enclosure does not exceed the rated temperature under direct solar load.

Can the DDR-60L-15 handle sub-zero temperatures in an unheated utility cabinet?

Yes. The operating temperature range extends down to -40°C, so it will start and regulate properly even in extreme winter conditions. Keep humidity within the rated 5-95% RH non-condensing range.

How does the DDR-60L-15 compare to the DDR-60G-15 in terms of input voltage range?

Both output 15V at 4A (60W) and share identical dimensions of 90.0 x 54.5 x 52.5 mm. The key difference is input range: the DDR-60G-15 accepts 9-36V DC (suited for 12V or 24V source buses), while the DDR-60L-15 accepts 18-75V DC (suited for 24V or 48V source buses). Choose based on your upstream DC voltage.
