Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well DDR-30L-12 DC-DC Converter - 30W - 18~75V in 12V out 2.5A

Name: Mean Well DDR-30L-12 DC-DC Converter - 30W - 18~75V in 12V out 2.5A
Brand: Mean Well
SKU: DDR-30L-12
Price: 33.06 USD
Availability: InStock

$33.06 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

The DDR-30L is a 30W DIN Rail type DC-DC converter with a 35mm (2SU) profile, suited for systems powered from 24V or 48V DC buses. A 4:1 wide input voltage range of 18~75Vdc covers nominal 24V and 48V supplies, and reinforced 4KVdc I/O isolation ensures clean, noise-resistant power conversion. Cooled by free air convection with no minimum load requirement, it operates across a -40~+85°C working range.

Key Features

✓ Compact 35mm (2SU) width — DIN rail TS-35/7.5 or 15 compatible
✓ 4:1 wide input voltage range: 18~75Vdc
✓ DC output voltage adjustable ±10%
✓ 4KVdc reinforced I/O isolation
✓ Cooling by free air convection — no minimum load required
✓ Wide operating temperature: -40°C ~ +85°C
✓ Protections: Short circuit / Overload / Over voltage / Reverse polarity / Under voltage lockout
✓ Safety approvals: UL 62368-1, IEC 62368-1, AS/NZS 62368.1
✓ 3 years warranty

Specifications

Brand

Mean Well
Series

DDR Series
Power Rating

30 Watt
Output Voltage

12 Volt
Rated Current

2.5 Ampere
Input Voltage

18V~75V
Standards Met

CE,EMC,UL
Operation Mode

Constant Voltage
Operating Temperature

-40°C~85°C
Warranty

2 Year
Length

2.15 in
Width

1.38 in
Height

3.54 in
Weight

0.26 lb
