Mean Well KNX-20U-640 KNX Power Supply 640mA
$81.33 USD
Unit price /
Unavailable
Description
Description
Features
| EIB/KNX power supply with integrated choke |
| Compact size with 3SU(52.5mm) width |
| Safety extra low voltage (SELV) |
| 180~264VAC input |
| No load power consumption <0.5W |
| Protections: Short circuit / Overload / Over voltage |
| Cooling by free air convection |
| Isolation class I |
| LED indicator for normal operation, bus reset, and bus overload |
| Installed on DIN rail TS-35/7.5 or 15 |
| Overvoltage category III |
| 100% full load burn-in test |
| 3 years warranty |
General Specification
| AC input voltage range | 180~264VAC; 230~370VDC |
| AC inrush current | Cold start 40A at 115VAC |
| Rated current | 640mA |
| Overload protection | 205%~235% rated output power, constant current limiting, auto-recovery |
| Over-voltage protection | 110%~117% rated output voltage |
| Setup, rise, backup time | 1000ms, 50ms, 200ms |
| Withstand voltage | I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:0.6KVAC |
| Working temperature | -30~+70°C |
| Vibration | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, and Z axes |
| Safety standards | BS EN/EN61558-1,BS EN/EN61558-2-16;BS EN/EN50491-3, EAC TP TC 004 approved |
| EMC standards | EN50491-5-2,3; EN61000-3-2,3; EN61000-4-2,3,4,5,6,8,11 |
| Connection | I/P: 3 poles, O/P: 2 poles screw DIN terminal + 2 bus terminal |
| Dimension (LxWxH) | 52.5x90x54.5 |
| Packing | 60pcs / 13.9kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesKNX Series
-
Power Rating19.2 Watt
-
Output Voltage30 Volt
-
Rated Current0.64 Ampere
-
Input Voltage180V~264V
-
Standards MetCE,EAC,KNX,TUV
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length3.54 in
-
Width2.15 in
-
Height2.07 in
-
Weight0.47 lb
