Mean Well DLW05C-15 DC-DC Converter - 5W - 36~72V in ±15V out 167mA

Name: Mean Well DLW05C-15 DC-DC Converter - 5W - 36~72V in ±15V out 167mA
Brand: Mean Well
SKU: DLW05C-15
Price: 16.61 USD
Availability: InStock

SKU DLW05C-15

$16.61 USD

Shipping calculated at checkout.

Available to order

Overview

DLW05C-15 is the ±15V output model of this series: rated power 5W, typical efficiency 85%.

Features

Specifications

DLW05C-15Specifications from the official datasheet (2024-08-02 edition)

OUTPUT

DC VOLTAGE: ±15V
CURRENT RANGE: ±16.7 ~ ±167mA
RATED POWER: 5W
RIPPLE & NOISE (max.)^Note.2: 60mVp-p
LINE REGULATION^Note.3: ±0.2%
LOAD REGULATION^Note.4: ±0.5%
VOLTAGE ACCURACY: ±2.0%
SWITCHING FREQUENCY: 50KHz min.

INPUT

VOLTAGE RANGE: 36 ~ 72VDC
EFFICIENCY (Typ.): 85%
DC CURRENT Full load: 135mA
DC CURRENT No load: 10mA
FILTER: Pi network
PROTECTION: Fuse recommended

PROTECTION (Note. 5)

OVERLOAD: 160 ~ 250% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
SHORT CIRCUIT: All output equipped with short circuit Protection type : Hiccup mode, recovers automatically after fault condition is removed

ENVIRONMENT

WORKING TEMP.: -25 ~ +71℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20% ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY: -25 ~ +105℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03% / ℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: EAC TP TC 020/2011 approved
WITHSTAND VOLTAGE: I/P-O/P:1.5KVDC
ISOLATION RESISTANCE: I/P-O/P: 100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55032 Class B, FCC part 15 Class B , EAC TP TC 020
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8, light industry level, criteria A , EAC TP TC 020

OTHERS

MTBF: 800khrs min. MIL-HDBK-217F(25℃)
DIMENSION: 50.8*25.4*11.27mm or 2.0"*1.0"*0.44" inch (L*W*H)
PACKING: 31.2g ; 10pcs/per tube, 400pcs/40 tube/per carton

Test conditions and notes5

1.All parameters are specified at normal input, rated load, 25℃ 70% RH ambient.
2.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
3.Line regulation is measured from low line to high line at rated load.
4.Load regulation is measured from 10% to 100% rated load.
5.Please prevent the converter from operating in overload or short circuit condition for more than 30 seconds.

Technical drawings

DLW05C-15 Mechanical Specification — Mechanical Specification

Downloads

Certificates2

EMC Certificate (DLW05)(EN) PDF Download

FCC Certificate (DLW05)(EN) PDF Download

Catalogues2

Mean Well DC-DC Catalog PDF Download

Mean Well Catalog (Industrial) PDF Download

FAQ

Can I use the DLW05C-15 in a 48V DC control system that needs a 15V rail?

This converter is intended for 36-72VDC input and provides a regulated ±15V dual output at 5W. It is a fit for low-power control, interface, or analog sections that need ±15V from a source in that higher input range.

Is the DLW05C-15 suitable for instrumentation or signal-conditioning electronics that require 15V?

Yes, it can suit instrumentation or signal-conditioning circuits that need a regulated ±15V rail, provided the available input is 36-72VDC. The 5W rating means it is intended for modest-power electronics rather than larger 15V loads.

Can this model be used in compact embedded systems with limited board space?

The package measures 50.8 × 25.4 × 11.27 mm and weighs 31.2 g, so it is built for compact layouts. That makes it practical for embedded assemblies that need ±15V conversion without using a larger power module.

Is the DLW05C-15 appropriate for outdoor equipment enclosures?

The specified operating range is -25°C to +71°C (with load derating per the derating curve), which supports a wide temperature span. No IP rating is listed in the specs, so the product data does not identify it as weather-resistant or outdoor-rated.

What are the output options in the DLW05C family?

The listed DLW05C siblings all use 36-72VDC input and 5W power. Output choices are ±5V with up to ±500mA for the DLW05C-05, ±12V with up to ±208mA for the DLW05C-12, and ±15V with up to ±167mA for the DLW05C-15.
