Ltech E5S Multi-zone Touch Panel - RGBWW

Name: Ltech E5S Multi-zone Touch Panel - RGBWW
Brand: Ltech
SKU: E5S
Price: 68.31 USD
Availability: InStock

SKU E5S

$68.31 USD ~~$147.42~~

Shipping calculated at checkout.

In stock

The Ltech E5S is designed to control RGB, RGBW, and RGB+CT LED lighting. It combines RF wireless control with PWM power output in one model, making it suitable for color-changing and tunable-white lighting applications. This makes it a flexible option for projects that need more than simple single-color dimming.

Input 12~24VDC. Operating temperature -20~+55°C. Backed by a 5 year warranty.

Key Features

✓Input voltage: 12~24VDC
✓Control protocol: PWM
✓Maximum total load: 144W
✓Operating temperature: -20~+55°C
✓Certifications: CE, FCC, RCM
✓Dimensions: 86 x 86 x 36mm
✓5 year warranty

Frequently Asked Questions

What does the Ltech E5S Multi-zone Touch Panel control?

Is the Ltech E5S only a wall panel, or does it also provide output for lighting control?

This model is more than a touch panel because it combines RF wireless control and PWM power output in a single unit. That 2-in-1 design helps distinguish it from panels that act only as control interfaces. It is intended for direct LED lighting control within its stated electrical ratings.

What are the electrical ratings of the Ltech E5S?

The Ltech E5S is rated for 24 V output, 12 A rated current, and 144 W power. Those published ratings define the operating range for this specific controller. Buyers should match the product to lighting systems that fit within those limits.

Does the Ltech E5S support smartphone control?

Yes, the touch panel can be controlled by smartphone if a compatible gateway is added. On its own, the product supports RF wireless control, and the gateway expands control options beyond direct remote use. This is useful for buyers who want smart-control capability without changing to a different controller model.

What type of dimming control does the Ltech E5S use?

The Ltech E5S uses PWM dimming control. PWM is commonly used for LED control because it supports smooth adjustment of brightness and color output in compatible lighting systems. For this model, PWM is part of its core control method.

Is the Ltech E5S suitable for demanding indoor environments?

The published operating temperature range is -20 degrees C to 55 degrees C, which supports use in a wide range of indoor commercial and architectural environments. Buyers with projects exposed to colder or warmer conditions should compare those conditions against this stated range. The product also carries a 5-year warranty period.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Outputs	Output Type	Dimming
Ltech Q5 Wireless RF Multi-zone Remote - RGBWW	—	—	—	View
Ltech F4-5A Wireless RF Constant Voltage Controller - 4 Channel	4	PWM	PWM	View
Ltech F4-3A Wireless RF Constant Voltage Controller - 4 Channel	4	PWM	PWM	View
Ltech T2M Wireless RF Multi-zone Remote - Colour Temperature	—	RF Signal	RF Signal	View
Ltech T2 Wireless RF Single-zone Remote - Colour Temperature	—	RF Signal	RF Signal	View
Ltech R4-CC Wireless RF Constant Current Controller - 4 Channel	4	PWM	PWM	View
Ltech M5+M3-3A Mini Controller with RF Remote - Colour Temperature	5	RF Signal	RF Signal	View
Ltech M2+M4-5A Mini Controller with RF Remote - Colour Temperature	4	RF Signal	RF Signal	View
Ltech F5-DMX-4A Wireless RF Constant Voltage Controller - 5 Channel	5	DMX Signal	DMX	View
Ltech F4-DMX-5A Wireless RF Constant Voltage Controller - 4 Channel	4	DMX Signal	DMX	View
Ltech F4-CC Wireless RF Constant Current Controller - 4 Channel	4	PWM	PWM	View
Ltech EX6 Wireless RF/DMX512 Multi-zone Touch Panel - Colour Temperature	—	DMX Signal	DMX	View
Ltech EX2 Wireless RF/DMX512 Single-zone Touch Panel - Colour Temperature	—	DMX Signal	DMX	View
Ltech E3S Single-zone Touch Panel - RGB	3	PWM	PWM	View
Ltech E2 Single-zone Touch Panel - Colour Temperature	2	PWM	PWM	View
Ltech DX6 Wireless RF/DMX512 Multi-zone Touch Panel - Colour Temperature	—	DMX Signal,RF Signal	DMX,RF Signal	View
