Mean Well ELG-200-C700DA Power Supply 200W 700mA - DALI | Mean Well LED Driver

Name: Mean Well ELG-200-C700DA Power Supply 200W 700mA - DALI
Brand: Mean Well
SKU: ELG-200-C700DA
Price: 58.22 USD
Availability: InStock

Overview

ELG-200-C700DA is the model of this series: rated current 700mA, typical efficiency 93%.

ELG-200-C series is a 200W LED AC/DC driver featuring the constant current mode and high voltage output. ELG-200-C operates from 100~305VAC and offers models with different rated current ranging between 700mA and 2100mA. Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for -40℃~+85℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. ELG-200-C is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Features

Constant current mode output
Metal housing design with functional Ground
Built-in active PFC function
No load / Standby power consumption <0.5W
IP67 / IP65 rating for indoor or outdoor installations
Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off); Smart timer dimming; DALI
Typical lifetime>50000 hours
5 years warranty

Specifications

ELG-200-C700DASpecifications from the official datasheet (2026-07-06 edition)

OUTPUT

RATED CURRENT: 700mA
RATED POWER 200VAC ~ 305VAC: 200.2W
RATED POWER 100VAC ~ 180VAC: 150.5W
CONSTANT CURRENT REGION^Note.2: 142 ~ 286V
OPEN CIRCUIT VOLTAGE(max.): 300V
CURRENT ADJ. RANGE: Adjustable for A/AB-Type only (via built-in potentiometer) 350 ~ 700mA
CURRENT RIPPLE: 5.0% max. @rated current
CURRENT TOLERANCE: ±5.0%
SET UP TIME^Note.4: 800ms/115VAC, 500ms/230VAC

INPUT

VOLTAGE RANGE^Note.3: 100 ~ 305VAC 142 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF≧0.97/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC@full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION: THD< 20%(@load≧50%/115VC,230VAC; @load≧75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION(THD)” section)
EFFICIENCY (Typ.): 93%
AC CURRENT (Typ.): 1.8A / 115VAC 1.0A / 230VAC 1.0A/277VAC
INRUSH CURRENT(Typ.): COLD START 65A(twidth=680μs measured at 50% Ipeak)/230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER: 2 units (circuit breaker of type B) / 4 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT: <0.75mA / 277VAC
NO LOAD / STANDBY POWER CONSUMPTION: No load power consumption <0.5W for Blank / A-Type Standby power consumption <0.5W for B / AB / DA-Type

PROTECTION

SHORT CIRCUIT: Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE: 315 ~ 370V Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.: Tcase=-40 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
MAX. CASE TEMP.: Tcase=+85℃
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 60℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS: UL8750(type”HL”), CSA C22.2 No. 250.13-12;BS EN/EN/AS/NZS 61347-1,BS EN/EN/AS/NZS 61347-2-13 independent, BS EN/EN62384;GB/T19510.1,GB/T19510.213;EAC TP TC 004;BIS IS15885(for 700A only); IP65 or IP67;KC61347-1,KC61347-2-13 approved
DALI STANDARDS: Compliance to IEC62386-101,102,(207 by request) for DA Type only
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55015,BS EN/EN61000-3-2 Class C (@load≧50%) ; BS EN/EN61000-3-3; GB/T 17743, GB17625.1; EAC TP TC 020; KC KN15,KN61547
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547, light industry level(surge immunity:Line-Earth:6KV, Line-Line:4KV);EAC TP TC 020; KC KN15,KN61547

OTHERS

MTBF: 2728.6K hrs min. Telcordia SR-332 (Bellcore) ;217.6K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 244*71*37.5 mm (L*W*H)
PACKING: 1.22Kg; 12pcs /15.2kg / 0.72CUFT

Certifications & ratings

Type: Type HL

Test conditions and notes11

1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
2. Please refer to "DRIVING METHODS OF LED MODULE".
3. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
4. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time.
5. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
6. This series meets the typical life expectancy of >50,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 85℃ or less.
7. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com
8. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
9. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf
10. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED power supply can only be used behind a switch without permanently connected to the mains.
11. For A/AB type need to consider build in using to comply with Type HL application.

Technical drawings

ELG-200-C700DA BLOCK DIAGRAM — BLOCK DIAGRAM

ELG-200-C700DA DIMMING OPERATION — DIMMING OPERATION

ELG-200-C700DA OUTPUT LOAD vs TEMPERATURE(Note.7) — OUTPUT LOAD vs TEMPERATURE(Note.7)

ELG-200-C700DA STATIC CHARACTERISTIC — STATIC CHARACTERISTIC

ELG-200-C700DA TOTAL HARMONIC DISTORTION — TOTAL HARMONIC DISTORTION

ELG-200-C700DA LIFETIME(Kh) — LIFETIME(Kh)

ELG-200-C700DA MECHANICAL SPECIFICATION — MECHANICAL SPECIFICATION

ELG-200-C700DA Dimensions (mm) — Dimensions (mm)

ELG-200-C700DA ※ B/DA-Type — ※ B/DA-Type

ELG-200-C700DA ※ 3Y Model (3-wire input) — ※ 3Y Model (3-wire input)

ELG-200-C700DA Recommend Mounting Direction — Recommend Mounting Direction

Typical applications

LED street lighting
LED harbar lighting
LED bay lighting
LED greenhouse lighting
LED flood lighting
Type "HL" for use in Class I, Division 2 hazardous (Classified) location.

Downloads

Certificates4

UL Certificate (ELG-200-C)(EN) PDF Download

CB Certificate (ELG-200-C)(EN) PDF Download

EMC Certificate (ELG-200-C)(EN) PDF Download

ENEC Certificate (ELG-200-C)(EN) PDF Download

Test reports1

Test Report (ELG-200-C700)(EN) PDF Download

Catalogues1

Mean Well LED Driver Catalog PDF Download

FAQ

Can the ELG-200-C700DA be integrated into a DALI lighting control system for commercial LED downlights?

Yes. The 'DA' suffix indicates native DALI dimming support, making this driver directly compatible with DALI bus controllers and building management systems that use DALI for luminaire control. At 200.2W and 700mA constant current, it can drive a full downlight array under digital DALI commands.

Is the ELG-200-C700DA suitable for large LED signage installations managed by a DALI controller?

Yes. The ELG-200-C700DA's DALI interface allows precise digital brightness control of LED signage modules connected in series. Its 142–286V CC voltage range accommodates strings of high-voltage LED modules, and the IP67 waterproof rating permits outdoor or semi-exposed sign cabinet installations.

Can the ELG-200-C700DA drive LED arrays in a smart building or IoT lighting infrastructure?

The DALI protocol on this driver enables integration with smart building lighting networks that use DALI as the control bus. Each driver can be individually addressed, grouped, and dimmed through the DALI controller. The 100–305VAC input range and -40°C to +85°C case temperature (Tcase) rating support diverse installation environments.

What LED loads are compatible with the ELG-200-C700DA?

The ELG-200-C700DA outputs a constant 700mA with a CC voltage range of 142–286V. LED loads in a series string must present a combined forward voltage within 142–286V at 700mA. The number of individual LEDs that fit depends on the forward voltage of each LED — this varies by LED type and cannot be stated as a fixed number.

How does the ELG-200-C700DA differ from the ELG-200-C700B in terms of dimming and protection?

Both the ELG-200-C700B and ELG-200-C700DA are rated IP67, share 200.2W output, and output 700mA constant current. The ELG-200-C700B uses analog (0–10V or PWM) dimming, while the ELG-200-C700DA uses the DALI digital dimming protocol. Choose based on whether your control infrastructure uses analog signals or a DALI bus.

Can the ELG-200-C700DA be installed outdoors or in washdown areas?

It can be installed outdoors: the IP67 rating protects against dust and temporary water immersion, making the driver suitable for outdoor luminaires and wet-rated enclosures. The sheet does not rate it for washdown. The -40°C to +85°C case temperature (Tcase) rating supports cold outdoor climates as well as warm installations within the derating curve.
